PANASONIC CONSUMER ELECTRONICS COMPANY
One Panasonic Way, Secaucus, New Jersey 07094
EY981001101 H1507 Printed in Japan
wise battery pack may not be fully
charged.
Cool down the charger when
charging more than two battery
packs consecutively.
Do not insert your fingers into con-
tact hole, when holding charger or
any other occasions.
CAUTION:
Do not use power source from an
engine generator.
Do not cover vent holes on the
charger and the battery pack.
.LAMP INDICATIONS
.LAMP INDICATIONS
Red Flashing
Red Lit
Green Flashing quickly
Orange Lit
Orange Flashing
Charger is plugged into the AC outlet.
Ready to charge.
Now charging
Charging is completed.
Battery pack is warm. Charging will begin
when temperature of battery pack drops.
Charging is not possible. Clogged with
dust or malfunction of the battery pack.
. SPECIFICATIONS
SPECIFICATIONS
Model EY0110
Electrical rating See the rating plate on the bottom of the charger.
Weight 0.78 k
,
(1.72 lbs.)
Charging time
7.2V 9.6 V 12V 15.6V 18V 24V
1.2Ah
EY9065
EY9066
EY9080
EY9086
EY9001
EY9006
20min.
1.7Ah
EY9180
EY9182
EY9101
25min.
2.0Ah
EY9168 EY9106 EY9136 EY9117
30min. 30min. 60min.
3.0Ah
EY9200 EY9230 EY9210
45min. 90min.
3.5Ah
EY9201 EY9231 EY9251
55min. 65min.
NOTE: This chart may include models that are not available in your area.
Please refer to the catalogue.
