4 EXPLODED VIEW
5 REPLACEMENT PARTS LIST
NOTE:
*B=only available as set
*C=available individually
Ref.No. Part No. Part Name & Description Remarks Per Unit
1 WEY0L10K3098 HOUSING A 1
2 WEY0L10K3107 SLIDE COVER 1
3 WEY0L10L2108 MODULE 1
4 WEY0L10L2618 FUSE 250V 3.15A 1
5 WEY0L10K3028 HOUSING B 1
6 WEY0L10K2058 POWER CORD A-2 PLUG 1
7 WEY0L10K6238 TORX TAPPING SCREW *C K3-20 4
- WEY0L10K8008 INDIVIDUAL BOX 1
- WEY0L10K8108 OPERATING INSTRUCTIONS 1
