36
37
38
39
32
33
34
35
31
29
30
40
41
43
42
44
23
24
25
26
21
22
20
19
18
27
28
1716
1
2
3
4
1514
13
12
5
7
6
10
8
9
11
D3277 Parts Diagram
REF PART # DESCRIPTION
01 XD3277001 DOMED SEAL WASHER
02 XD3277002 SWITCH KNOB
03 XD3277003 SWITCH POLE
04 XD3277004 LOCKED SPRING
05 XD3277005 NOZZLE NUT
06 XD3277006 SEAL WASHER 30MM
07 XD3277007 ATOMIZATION
08 XD3277008 FLUID NOZZLE
09 XD3277009 FLUID NOZZLE PLUG
10 XD3277010 SEAL WASHER 10MM
11 XD3277011 DIRECTION SCREW
12 XD3277012 DOMED SEAL WASHER
13 XD3277013 SPRING
14 XD3277014 TRIGGER PIN I
15 XD3277015 TRIGGER PIN II
16 XD3277016 TRIGGER
17 XPEC02M E-CLIP 4MM
18 XPEC02M E-CLIP 4MM
19 XD3277019 BREATHER PLUG
20 XD3277020 CONTAINER COVER
21 XD3277021 CONTAINER
22 XD3277022 FILTER
REF PART # DESCRIPTION
23 XD3277023 FLUID INLET JOINT
24 XPEC09M E-CLIP 6MM
25 XD3277025 O-RING
26 XD3277026 PATTERN ADJ.
27 XD3277027 COPPER WASHER 8MM
28 XD3277028 PATTERN ADJ. KNOB
29 XD3277029 PATTERN ADJ. SCREW
30 XPFH31M FLAT HD SCR M6-1 X 8
31 XD3277031 FLUID ADJ. KNOB
32 XD3277032 JOINT CAP
33 XD3277033 FLUID NEEDLE SPRING
34 XD3277034 FLUID ADJ. NEEDLE
35 XD3277035 MODULATOR
36 XD3277036 SWITCH SPRING
37 XD3277037 SWITCH BLOCK
38 XD3277038 O-RING
39 XD3277039 SPECIAL SET SCREW M4 X 14
40 XD3277040 GUN BODY
41 XD3277041 AIR INLET PLUG
42 XD3277042 MULTI-TOOL WRENCH
43 XD3277043 HEX SOCKET TOOL
44 XD3277044 BRUSH
