Model W1776 2" Nailer Kit
-10-
A jammed nail must be cleared before
using the nailer again.
To clear a jammed nail from the dis-
charge area, do these steps:
1. DISCONNECT NAILER FROM THE AIR
SUPPLY!
2. Unlatch and pull the magazine all the
way back.
3. Remove the nail stick from the
magazine.
4. Open the nailer nose with the nose
release lever (see Figure 6).
Clearing Jammed Nails
5. Remove the jammed nail with a
tool that will fit in the slot on the
underside of the nose, such as needle
nose pliers.
6. Throw the damaged nail away and
insert a new nail stick that only
contains clean, undamaged nails. DO
NOT use dirty or damaged nails!
7. Close the nose cover, and push the
magazine all the way forward until
the catch lever locks it in place.
Figure 6. Nose opened to clear jam.
Nose Cover
Nose Release Lever
