Subaru RGX7500E Welding System User Manual



RGX7500 - 43 - 03-12
Ref. Part Number Description Qty Remarks Model
FIG. 24 GROUP
100 35H-70103-00 CONTROL BOX AY 1
110 35G-71101-02 CONTROL BOX UN 1
303 31H-74001-01 AVR UN 1
310 392-49986-08 SCREW 4 M4X6L
360 353-45815-08 DIODE STACK AY 1
362 35G-72015-03 SCREW 1
363 002-17040-00 NUT 1
370 KU3-11015-01 IDLE C/U CP (150V) 1
372 001-13062-00 BOLT AND WASHER AY 2
373 002-17060-00 NUT 2 M6X1.0X5H
480 35C-72014-03 FLANGE BOLT 5
490 31H-75009-03 GROMMET 1
500 35H-70203-00 CONTROL PANEL AY 1 Recoil Only
500 35H-70204-00 CONTROL PANEL AY 1 Electric Start Only
505 35G-71001-01 CONTROL PANEL 1 Recoil Only
505 35G-71002-01 CONTROL PANEL 1 Electric Start Only
520 35A-72002-03 ROCKER SWITCH 1 Recoil Only
520 066-00003-30 SWITCH 1 Electric Start Only
520-1 066-00099-80 KEY,SWITCH 2 MARK 103 Electric Start Only
523 344-45615-08 AUTO IDLE SWITCH 1
526 355-45613-11 SWITCH AY(9P) 1
530 35B-72003-03 AC RECEPTACLE 1 125V/30A
531 35C-72005-03 AC RECEPTACLE 1
532 388-85003-01 AC RECEPTACLE 2 125V-20A
535 31C-79001-03 SCREW & WASHER AY 4
536 351-49920-08 SCREW & WASHER AY 4
537 002-37040-00 FLANGE NUT 4
565 393-40651-08 HOUR METER 1 60HZ
572 30G-45308-08 LAMP 1
660 31H-75025-03 BREAKER 1
661 352-45620-08 CIRCUIT PROTECTOR 1
665 31B-79011-03 SCREW & WASHER AY 4
666 351-49921-08 SCREW & WASHER AY 2
671 363-45701-08 TERMINAL 1 RED 10A
672 363-45700-08 TERMINAL 1 BLACK 10A
680 356-49956-08 SCREW 1
681 332-00050-08 SPRING WASHER 2
682 353-49903-08 WASHER 1
683 353-49902-08 NUT 1
684 372-59950-08 LOCK WASHER 1
685 353-49901-08 WING NUT 1
720 31B-79012-03 BOLT AND WASHER AY 4
767 31H-75028-03 CABLE CLIP 2 Electric Start Only
902 35H-71201-02 LABEL(MODEL) 1
