30 Chapter 1
Hibernation Mode
Enter Hibernation Mode (suspend to HDD)
when
1.Hibernation hot-key is pressed and
system is ready to enter Hibernation mode
2.System Hibernation timer expires and
system is ready to enter Hibernation mode.
T All power shuts off
Display Standby Mode
Keyboard, built-in touchpad, and an external
PS/2 pointing device are idle for a specified
period.
T The display shuts off
Hard Disk Standby Mode
Hard disk is idle within a specified period of
time.
T Hard disk drive is in standby mode.
(spindle turned-off)
Environmental Requirements
Item Specification
Temperature
Operating
+5~+35
°C
Non-operating
-20~+60 °C
Humidity
Operating 10% to 95% RH, non-condensing without disktte
10% to 80% RH, non-condensing with disktte
Non-operating 20% to 80% RH, non-condensing (Unpacked)
Non-operating 20% to 90% RH, non-condensing (Storage package)
Vibration
Operating 5~250Hz 0.5Grms, 15mins per axis
Non-operating (unpacked) 1.04 Grms, 2-200Hz 15 mins per axis
Non-operating (packed) 1.04 Grms, 2-200Hz 15 mins per axis
Mechanical Specification
Item Specification
Dimensions 322(W) x 294(D) x 39.4~39.9(H)mm
Weight 7.2 Ibs for 14.1” TFT LCD model with battery/7.4 Ibs for 15”LCD model with battery
I/O Ports Two Type II or one Type III PC CardBus (PCMCIA) slot
One IEEE 1394 port
One FIR port
One RJ-11 modem jack (V.92, 56K)
One RJ-45 network jack
One DC-in jack
One parallel port (ECP/EPP)
One S-video port
One external monitor port
One microphone-in jack (3.5mm mini jack)
One headphone jack (3.5mm mini jack)
Four USB ports
Drive Bays One
Material Plastic
Power Management
Power Saving Mode Phenomenon
