Test Record Performance Tests
Agilent 81480A and 81680A, 40A, 82A, 42A, & 89A Tunable Laser Modules User’s Guide, Sixth Edition 109
Agilent 81480A Performance Test
Page 11 of 13
Model Agilent 81480A Tunable Laser Report No. ________ Date_______
Power Stability
1
Power Stability = Maximum Deviation – Minimum Deviation
Signal-to-Source Spontaneous Emission - 81480A
Output 2, High Power
Measurement Uncertainty: ± 0.20 dB
Low SSE Output 1 High Power Output 2
Att = 0 dB
Maximum Deviation dB dB
Minimum Deviation dB dB
Power Stability
1
dB dB
Specification 0.02 dBpp 0.02 dBpp
Measurement Uncertainty ±0.005 dB ±0.005 dB
Wavelength Output Power Results
Maximum
Specification
1370.000 nm − 3.00 dBm dB 35 dB
1380.000 nm − 3.00 dBm dB 35 dB
1390.000 nm − 3.00 dBm dB 35 dB
1400.000 nm − 3.00 dBm dB 35 dB
1410.000 nm − 3.00 dBm dB 35 dB
1420.000 nm + 3.00 dBm dB 40 dB
1430.000 nm + 3.00 dBm dB 40 dB
1440.000 nm + 3.00 dBm dB 40 dB
1450.000 nm + 3.00 dBm dB 40 dB
1460.000 nm + 3.00 dBm dB 40 dB
1470.000 nm + 3.00 dBm dB 40 dB
1480.000 nm − 3.00 dBm dB 35 dB
