All Prices Exclude VAT
WE ARE PLEASED TO ACCEPT 7
3-5 Way Distribution Unit
• IP55 distribution board with
smoked lid
• Metal DIN rail
• Resistant to heat, shocks,
atmospheric agents and U.V. rays
• Thermoplastic material with
insulating and self-extinguishing
properties in conformity with IEC
695-2-1 (Glow-wire 650°C)
• Fully compliant and tested to BSEN60439-3
• CE marked
• Half din rail construction
• Remove MCB’s without
removing the busbar
• Plenty of cut outs for ease of
wiring
• Clear labelling to assist
identification
• Substantial cable entry and
wiring space
• Stylish, user friendly design
Insulated Surface
Consumer Units – Split
Load Protection
• Supplied complete with mains
isolator, RCCB and cable
• Additional copper bus bar supplied
• Fully compliant and tested to
BSEN60439-3, (Isolators
BSEN60947-3, RCCB BSEN61008-1)
• CE marked
• Connection leads manufactured from highly flexible copper
498021
RCCB Mains
Isolator Switches
• Fully compliant and tested to
BSEN60947-3
• 35mm terminal capacity
• Snap fitting to standard DIN rail
• Two module, double pole
Miniature Circuit
Breakers (MCB)
• Fully compliant and
tested to BSEN60898
• Fully shrouded line
and load terminals
will accept cables up
to 25mm square
• Positive contact
identification
• Single pole, 230V AC,
10KA
PL1013008 63A
PL1013108 80A
DP Isolator
Switches
• Fully compliant and tested to BSEN60947-3
• 35mm terminal capacity
• Positive contact identification in accordance
with 16th edition wiring regulations 537-02-
03 and 537-03-20
• Two module, double pole
1+ 3+
£6.25 £5.93
order code EN8132008
Insulated Consumer Units
498023
Type
Current
Rating
Trip
Current
Dims.
(LxWxD) mm 1+ 2+
PL1012008 4+4 63A 30mA 340x231x115 £48.87 £46.43
PL1012108 4+4 80A 30mA 340x231x115 £53.39 £51.05
PL1012208 6+6 63A 30mA 411x231x115 £59.86 £55.41
PL1012308 6+6 80A 30mA 411x231x115 £65.00 £61.00
PL1012408 9+9 63A 100mA 520x231x115 £72.01 £69.21
PL1012508 9+9 63A 30mA 520x231x115 £88.98 £84.53
PL1012608 9+9 80A 100mA 520x231x115 £86.00 £81.70
PL1012708 9+9 80A 30mA 520x231x115 £82.00 £77.90
PL1012808 9+9 100A 100mA 520x231x115 £84.25 £79.98
PL1012908 9+9 100A 30mA 520x231x115 £86.05 £81.33
497757
495750
498022
1+ 5+
£7.98 £7.45
1+ 3+
PL1013208 63A 30mA £28.37 £27.41
PL1013308 80A 30mA £34.02 £32.35
PL1013408 63A 100mA £26.06 £25.24
PL1013508 80A 100mA £31.40 £29.87
PL1013608 100A 30mA £37.08 £36.05
PL1013708 100A 100mA £35.00 £34.21
£2.73
B Curve
1+ 5+
PL1013808 6A £2.98 £2.73
PL1013908 10A £2.98 £2.73
PL1014008 16A £2.98 £2.73
PL1014108 20A £2.98 £2.73
PL1014208 32A £2.98 £2.73
PL1014308 40A £2.98 £2.73
PL1014408 50A £2.98 £2.73
C Curve
PL1014508 6A £3.24 £2.88
PL1014608 10A £3.24 £2.88
PL1014708 16A £3.24 £2.88
£11.54
1+ 3+
PL1011608 4 Way 196x231x115 £12.35 £11.54
PL1011708 6 Way 268x231x115 £13.36 £12.21
PL1011808 10 Way 340x231x115 £14.25 £13.29
PL1011908 14 Way 411x231x115 £17.49 £16.62
495749
