Cable glands that are suitable for
Steel Wired Armoured, plastic
and rubber sheathed cables. The
gland is ideal for use in most
climatic conditions, and will
provide an IP rating of IP66.
CBBR009308 Blue 100m Reel £76.69 £71.24
4.00mm
CBBR828208 Blue 100m Reel £129.98 £126.05
CBBR009108 Blue 100m Reel £43.25 £40.89
2.50mm
CBBR009208 Yellow 100m Reel £76.69 £71.24
CBBR151808 Blue 100m Reel £29.98 £26.05
1.50mm
CBBR009008 Yellow 100m Reel £43.25 £40.89
0.75mm
1+ 3+
CBBR151708 Yellow 100m Reel £29.98 £26.05
All Prices Exclude VAT
TRADES - WHAT YOU NEED AT LOW PRICES 21
A very flexible three-core, round
profile cable, using a special grade
PVC that makes it suitable for use
down to temperatures -20°C. This
makes it ideal for use in very cold
environments as well as outdoors. The
cable conforms to BS6500 and is
supplied by the metre and 100m reels.
497751
Note: Core colours are now
Brown and Blue
Low Voltage Lighting
Cable
• PVC insulated & sheath
• 2x 2.0mm copper
conductors
• Voltage rating up to 50V
• Outer diameter: 8x4.5 mm
Steel Wire Armoured Cable
Harmonised Core Colours
• Suitable for mains supply electricity and can be
used externally or buried.
• Cross linked polyethelene (XLPE) insulated
booklet armoured cables benefit from superior
thermal and mechanical properties
• Conform to: BS6360 - Conductors, BS6746
Type 9 - Sheath, BS1442 - Armour
Technical Data
Conductors Stranded Annealed Copper
Insulation XLPE (cross linked polyethylene) PVC
Bedding Extruded PVC
Armour Galvanised Steel wire armour
Sheath PVC
Voltage 600/1000V
Operating temperature -40°C to 90°C
Colour Codes:- 3 core - Brown, Black, Grey. 4 core
- Brown, Black, Grey, Blue.
3-Core 6943X
Size
(mm
2
) O/D (mm) Reel (m) 1+ 3+
CB0927108 1.5 12.9 50 £45.58 £43.25
CB0927308 2.5 13.8 50 £69.21 £62.69
CB0927408 2.5 13.8 100 £118.05 £113.36
CB0927608 6 17.4 50 £107.98 £101.35
4-Core 6944X
CB0928008 2.5 14.7 50 £58.16 £54.34
CB0928108 2.5 14.7 100 £147.96 £144.57
Technical Data
Type Thread Cable Dia Min. / Max. Thread Length
20mm Small M20 12.90mm / 15.80mm 10.00mm
20mm M20 15.50mm / 20.80mm 10.00mm
25mm M25 19.50mm / 26.50mm 10.00mm
32mm M32 26.70mm / 33.50mm 10.00mm
1+ 5+
CBBR456008 20mm Small £0.85 £0.80
CBBR456108 20mm £0.99 £0.89
CBBR456208 25mm £2.05 £1.88
CBBR456308 32mm £2.69 £2.41
Steel Wire Armoured Cable
Glands - Type BW
Cable glands that are suitable
for Steel Wired Armoured,
plastic and rubber sheathed
cables. The gland is ideal for use in
dry conditions and will provide an
IP rating of IP54.
495574
The kit contains - 2 Brass Glands
2 PVC Shrouds
2 Brass Locknuts
2 Earth Tags
2 Outer Seals (within the gland)
Technical Data
Type Thread Cable Dia Min. / Max. Thread Length
20mm Small M20 11.00mm / 16.00mm 10.00mm
20mm M20 14.50mm / 21.00mm 10.00mm
25mm M25 20.30mm / 27.60mm 10.00mm
1+ 5+
CBBR456408 20mm Small £1.81 £1.62
CBBR456508 20mm £2.18 £1.99
CBBR456608 25mm £3.41 £3.05
Steel Wire Armoured
Cable Glands - Type CW
497752
3183YAG 300/500V Three-Core
Round Arctic Flex
The kit contains -
2 PVC Shrouds
2 Brass Locknuts
2 Earth Tags
2 Brass Glands
1+ 3+
£47.98 £43.58
order code CBBR822208
497810
• Maximum current 17.5A
• Supplied in 100m reels
Technical Data
O/D (mm) CurrentRating Nominal Strands/mm CSA (mm)
7.50 6A 24/0.20 3 x 0.75
8.90 15A 30/0.25 3 x 1.50
10.80 20A 50/0.25 3 x 2.50
£26.05
497835
