3 - 5
PHOTOMETER ASSEMBLY
ETC00781(4) Series 100 e 02/2004
GAS DETECTOR
Fig. 3-2: Photometer Assembly 100 Series with Gas Detector
[example above and middle: high measuring ranges,
example below: small measuring ranges.
1 Analysis Cell
2 Filter Cell
3 Gas Detector
4 Holding Device
5 Preamplifier
6 Absorber
3521
44
16 5 4 623
