Changing the Print Settings
You can change many print settings such as print direction and loading
position. Because these settings take effect each time you turn on the
printer, they are also called default settings.
The factory default settings are designed to meet the needs of most users,
so you may not need to change them. The table below lists the features
you can select in the default-setting mode.
Settings Options
Print direction Auto, Bi-D, Uni-D
Font Courier, Roman, Sans Serif, Prestige, Script,
Roman T, Sans Serif H, Draft
Pitch 10 cpi, 12 cpi, 15 cpi, 17.1 cpi, 20 cpi, Proportional
I/F mode Auto, Parallel, Serial, Option
Auto I/F wait time 10 seconds, 30 seconds
Software ESC/P 2, IBM X24E
Auto CR (IBM mode only) Off, On
AGM (IBM mode only) Off, On
Character table Standard model:
Italic, PC437, PC850, PC860, PC863, PC865,
PC861, BRASCII, Abicomp, Roman 8, ISO Latin 1
All other models:
Italic, PC437, PC437 Greek, PC850, PC853,
PC855, PC852, PC857, PC866, PC 869,
MAZOWIA, Code MJK, ISO 8859-7, Bulgaria,
ISO Latin 1T, PC774, Estonia, ISO 8859-2,
PC866 LAT, PC866 UKR, PCAPTEC, PC708,
PC720, PCAR864, PC860, PC865, PC861
International character
set for Italic table
Italic U.S.A, Italic France, Italic Germany,
Italic U.K, Italic Denmark1, Italic Sweden,
Italic Italy, Italic Spain1
Auto line feed Off, On
Network I/F mode Off, On
Loading position 8.5 mm, 3 mm, Others
Economy Off, On
Parallel I/F transfer rate Fast, Normal
A
R
Easter10 Ref. Guide
Rev.C
A5 size Appendix A
1-07-98 DR, pass 1
Using the Printer with DOS
A-3
