You can use the front, bottom, or rear paper slot with the pull
tractor.
Paper slot Description
front
If you print on thick paper such as multi-part forms
or continuous paper with labels, use the front paper
slot because this paper path is almost straight. This
reduces the chance of paper jams.
bottom
The bottom paper slot has the straightest paper
path, so it is the best slot to use when printing on thick
paper, such as multi-part forms or continuous paper
with labels.
Note:
When loading paper in the bottom slot, be sure to
use a printer stand with an opening large enough
for the paper to feed through it without obstruction
.
rear
You can also load continuous paper from the rear
pull tractor position.
Note:
Paper loaded from the rear slot results in a curved
paper path, which may affect loading
performance, so use the front or bottom slot
whenever possible.
Caution:
Do not load continuous paper with labels in the rear
slot; the labels may come off their backing sheet
inside the printer and cause a paper jam.
