Appendix E IBM ProPrinter 4207, 4208 XL 24 Quick Refernce Appendix E IBM ProPrinter 4207, 4208 XL 24 Quick Refernce
E-19 E-20
Table 7 (Cont.): Further Control Sequences, supported by
IBM Emulation Mode (Native Commands)
Escape Sequence Mnemonic Function
ESC [ ; P2 ; P3 ; P4 ; P5 ; P6 ; P7 SP z
see Appendix G BH Barcode Header
BARCODE Programming P2: Barcode typ
P3: Height of barcode
P4: Width of the thin bars
P5: Width of the thin gaps
P6: Ratio width to thin
P7: Uni-directional or bi-directional
printing
0 : or not programmed: means no
changes
1 : uni-directional printing in LQ
2 : bi-directional printing in LQ
3 : uni-directional printing in NLQ
4 : bi-directional printing in NLQ
Note: A switch from uni-directional to bi-
directional printing is only possible if the
parameter UNI-DIRECT.CMD is set to YES
via operator panel or ESC-sequence.
ESC [ ? 0 h SMBC Set Mode Barcode
ESC [ ? 0 l RSBC Reset Mode Barcode
Hex Code Format Page
00 Null E-3
08 Backspace E-3
09 Horizontal Tab E-3
0A Line Feed E-3
0B Vertical Tab E-3
0C Form Feed E-3
0D Carriage Return E-3
0E Select Double Width (one line) E-3
0F Select Condensed Mode (17,1 cpi) E-3
11 Select Printer E-3
12 Select Pica (10 cpi) E-3
13 Buffer Data Flow Control E-3
14 Cancel Double Width E-3
18 Cancel Buffer E-3
1B Escape E-3
20 Space E-3
7F Delete E-3
1B 30 Set Line Space to / " E-4
1
8
1B 31 Set Line Space to / " E-4
7
72
1B 32 Start Variable Line Space E-4
1B 34 Set Top Of Form E-4
1B 36 Select Character Set 2 E-11
1B 37 Select CHaracter Set 1 E-11
1B 3A Select Elite (12 cpi) E-7
1B 3B Set Left Margin at Current E-9
1B 3C Home Position of Printhead E-9
1B 45 Select Emphasized (bold) E-8
1B 46 Cancel Emphasized E-8
1B 47 Select Double Strike (bold) E-8
1B 48 Cancel Double Strike E-8
1B 4D Reverse Line Feed E-16
1B 4F Cancel Automatic Perforation Skip E-4
1B 52 Restore Horizontal Tabs to Default E-8
