Fuse/Relay
Location
Fuse Amp
Rating
Protected Circuits
207 — Not used
208 — Not used
209
1
⁄
2
ISO relay Horn
301 Full ISO relay Starter
302 Full ISO relay Air compressor (non-Police
vehicles only)
RUN/ACC relay (Police vehicles
only)
303 Full ISO relay Blower
304 Full ISO relay Rear defrost relay
501 — Not used
502 Diode PCM
503 — Not used
601 20A Circuit
breaker
Power seats, Lumbar, Decklid
(Police vehicles only)
602 20A Circuit
breaker
RUN/ACC relay (windows)
(non-Police vehicles only)
RUN/ACC relay feed (windows
and decklid) (Police vehicles
only)
* Mini fuse ** Cartridge fuse
Relays
Relays are located in the power distribution box and should be replaced
by an authorized dealer.
CHANGING A FLAT TIRE
If you get a flat tire while driving:
• do not brake heavily.
• gradually decrease the vehicle’s speed.
• hold the steering wheel firmly.
• slowly move to a safe place on the side of the road.
Your vehicle may be equipped with a conventional spare tire that is
different in one or more of the following: type, brand, size, speed rating
2009 Crown Victoria (cro)
Owners Guide, 2nd Printing
USA (fus)
Roadside Emergencies
195
