SKU 66995 For technical questions, please call 1-800-444-3353. Page 14

Part Description Q’ty

1 Exhaust Cover 1

2 Hex Bolt 4

3 Cylinder Cap Unit 1

4 Seal 1

5 Seal 1

6 O-Ring 1

7 Compression Spring 1

8 Gasket 1

9 O-Ring 1

10 Head Valve Piston 1

11 O-Ring 1

12 O-Ring 1

13 O-Ring 1

14 Collar 1

15 O-Ring 1

16 Driver 1

17 Fixed Ring 1

18 O-Ring 1

19 Lining Ring 1

20 O-Ring 1

21 Cylinder 1

22 O-Ring 1

23 Bumper 1

24 Housing 1

25 Nozzle 1

26 Seal 1

27 Trigger Valve Head 1

28 Trigger Valve Plunger 1

29 O-Ring 1

30 O-Ring 1

31 Trigger Valve Body 1

32 Spring 1

33 Trigger Plate 1

34 O-Ring 1

35 Trigger 1

36 Pin 1

Part Description Q’ty

37 Spring Pin 1

38 Guide 1

39 Spring Pin 2

40 Hex Bolt 1

41 Stopper 1

42 Spring 1

43 Safety Cover 1

44 Hex Bolt 4

45 Safety 1

46 Spacer 1

47 Driver Guide Cover 1

48 Hex Bolt 2

49 Driver Guide 1

50 Magazine 1

51 Steel Bar 1

52 Pusher Unit 1

53 Spring Holder 2

54 O-Ring 2

55 Pin 1

56 Side Cover 1

57 Latch 1

58 Spring 1

59 Tail Cover 1

60 Hex Bolt 1

61 Hex Bolt 1

62 Spring Pin 1

63 Nut 1

64 Hex Bolt 1

65 Hex Bolt 1

66 Hex Bolt 1

67 Tail Hanger 1

68 Lock Nut 1

69 Hand Grip 1

70 O-Ring 1

71 End Cap 1

72 Air Plug 1

PARTS LIST

Record Product’s Serial Number Here:

Note: If product has no serial number, record month and year of purchase instead.

Note: Some parts are listed and shown for illustration purposes only, and are not avail-

able individually as replacement parts.
