Service
Deskside Pedestal Base
97
Service
Deskside Pedestal Base
CAUTION! Before removing the pedestal bases, disconnect cables to prevent stressing
the cables and connectors.
To remove a deskside pedestal base (Figure 45):
1. Lay the enclosure on its top.
2. Push the pedestal base (12) toward the center to unlatch it, then lift the outer edge.
3. To replace a pedestal base, insert the inner tabs then snap the outside edge in place.
