6-27Removal and Replacement
Figure 6-19.
Motor Screws (2)
Worm Gear
Paper Motor
Paper Motor
Encoder
Connector
Mark must face
toward front of
plotter when
paper motor is
fully installed
Drive Roller Gear
Front View
(C)C2858-47a
(C)C2858-66
