Repair Information 4-9
4069-XXX
M3x6 mm
Tapti te
outer shield mounting 6
inner redrive deflector mounting 2
interconnect board to
center pan
mounting 2
engine board
(bottom holes)
mounting 2
controller board to
interconnect board
ground
attach 2
controller board to inner
shield
mounting 2
controller board (back) mounting 2
engine board to
interconnect shield
ground
attach 1
lower stacker duct mounting 1
ground cables to ground
(center pan - front)
attach 1
cable clip (main drive
gearbox, BTM)
mounting 2
fuser screw mounting 7
M3x8 mm
Tapti te
LVPS mounting 2
auto compensator
hanger bracket
mounting 1
Reference
Number
Screw Type Location Purpose Qty
