HOW TO USE
Control Panel
* Depending on the model, some of the following functions may not be available.
Control Panel Features
Ice SelectionIce Selection
Press the ice selection button to choose either cubed or
crushed ice. The cube or crush ice icon will illuminate.
Refrigerator Temperature Refrigerator Temperature
Indicates the set temperature of the refrigerator compart-
ment in Celsius (°C) or Fahrenheit (°F).
Freezer Temperature Freezer Temperature
Indicates the set temperature of the freezer compartment in
Celsius (°C) or Fahrenheit (°F).
To change the temperature mode from °F to °C (or vice
versa) press and hold the Refrigerator and Freezer tempera-
ture buttons simultaneously for approximately five seconds.
The temperature indication on the display window switches
between Celsius and Fahrenheit.
Fresh Air FilterFresh Air Filter
The Fresh Air Filter helps remove odors from the refrigerator.
The Fresh Air Filter has two settings, Auto and Power(PWR).
In Auto mode, the Fresh Air Filter will cycle on and off in
increments of ten minutes on and one hundred ten minutes
off. If set to the Power(PWR) mode, the Fresh Air Filter will
stay on continuously for four hours, cycling on and off in
increments of ten minutes on and five minutes off. After four
hours, the Fresh Air Filter will switch back to Auto mode.
The Press the Air Filter button once for Power(PWR)
y
mode.
Press the Air Filter button again to switch back to
y
Auto mode.
NOTE
The displayed temperature is the target temperature,
and not the actual temperature of the refrigerator.
The actual refrigerator temperature depends on the
food inside the refrigerator.
LED Display
Indicator
Control
Button
[
]
* LFX31925SW
LFX31925SB
