EtherFast
®
Cable/DSL Routers
Instant Broadband
™
Series
83
4-Port Router Specifications
Model Number BEFSR41 v2
Standards IEEE 802.3 (10BaseT), IEEE 802.3u (100BaseTX)
Protocol CSMA/CD
Ports
LAN: Four 10/100 RJ-45 switched ports
WAN: One 10Base-T Ethernet RJ-45 port for the cable or
DSL modem
Speed
LAN: 10/100Mbps
WAN: 10Mbps
Cabling Type
10BaseT: UTP Category 3 or better
100BaseTX: UTP Category 5 or better
Topology Star
LED Indicators Power,
LAN: Link/Act, Full/Coll, 100
WAN: Link, Act, Diag
4-Port Environmental Specifications
Dimensions 7.31" x 6.16" x 1.88" (186mm x 154mm x 48mm)
Unit Weight 13.4 oz. (0.42 kg)
Power Input External, 9V AC, 1 Amp
Certifications FCC Class B, CE Mark Commercial
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 70°C (-4°F to 158°F)
Operating Humidity 10% to 85%, Non-condensing
Storage Humidity 5% to 90%, Non-condensing
• Straight-Through Cabling
• Cross-Over Cabling
Crimping Your Own Network Cables
84
