Video resolution
This section is for making the settings for video output resolution. Set them depending on the connected
television.
Press RESOLUTION.
•The resolution is changed as shown below each time RESOLUTION is pressed.
•You cannot set resolution individually for each HDMI output.
•When you press and hold RESOLUTION with the resolution appearing on the
display, “HDMI Init.” appears on the display and the setting returns to the
default.
•The default settings is underlined.
Auto
480/576i
1080P24
1080P
1080i
480/576P
720P
Source Direct
(Auto)
(1080 progressive, 24-frame)
(Source direct)
(1080 progressive)
(480/576 interlaced)
(1080 interlaced)
(480/576 progressive)
(720 progressive)
•If the video resolution is not set to “Auto”, set it to correspond with the resolution of your television/AV
receiver.
•Images will not be projected normally if the television/AV receiver resolution and this unit’s output
resolution do not match.
•Audio and video will be temporarily interrupted if the power of the connected device currently playing is
turned off, or the input is switched.
•When you change the video resolution of the unit, it takes a few seconds up to about 10 seconds for
validation between the unit and the connected device. Audio/video is not output during this period.
