MTX-60 RAMMER • OPERATION AND PARTS MANUAL — REV. #6 (08/23/11) — PAGE 33
FUEL TANK AND HANDLE ASSY.
FUEL TANK AND HANDLE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 368347630 SHOCK ABSORBER W/ PIN 2
2-1 001521020 SOCKET HEAD BOLT 10X20 T 4
2-2 033121009 TOOTHED LOCK WASHER B M10 4
3 368119570 HANDLE 1
4-1 001211020 BOLT 10X20 H 4
4-2 030210250 WASHER, LOCK M10 4
5 939010270 RUBBER STOPPER (70) 1
6 030208200 WASHER, LOCK M8 1
7 020308060 NUT M8 1
8
*
366010060 TANK CAP STRAP 1
9 366345570 FUEL TANK CAP ASSY ............................................... 1 ........INCLUDES ITEM W/
*
10 368119460 FUEL TANK 2L 1
11 094010053 PAN HEAD SCREW 4X8 4
12-1 001210815 BOLT 8X15 H 3
12-2 030208200 WASHER, LOCK M8 3
13 952401450 WASHER 8.5X22X3 2
14 031108160 WASHER, FLAT M8 1
15 959300770 STRAINER #508 1
16 366459790 FUEL TANK PACKING 1
17 366345280 FILTER HOLDER .......................................................... 1 ........S/N T-3423 AND BELOW
17% 366349420 FILTER HOLDER W/V .................................................. 1 ........S/N T-3424 AND ABOVE
18 020305040 NUT M5 3
19 030205130 WASHER, LOCK M5 3
20 959026122 FUEL HOSE L=70 1
21 954406420 HOSE BAND 10.5 2
23 009110037 TAPPING SCREW 5X20 2
40 366910030 ROLLER ASSY W/ SCREW .........................................1 ........ INCLUDES ITEM W/ #
41# 366217170 ROLLER 2
42# 091005020 SCREW 5X20 4
43# 022610505 FLANGE NUT M5 H 4
51 980010330 TACHO & HOUR METER 1
53 955010305 CURL CORD TP-22 1
54 366345620 METER FINISHER 1
55 454010020 CLAMP TC-100 5
56 954010270 CLIP AB-3N 1
101 954406420 HOSE BAND 10.5 4
102 16910Z4ES21 FUEL STRAINER 1
103 959026103 FUEL HOSE 5.5X11.5X80 1
104 950014500150M FUEL HOSE 1M 1
106 950033606020 VINYL TUBE L260 1
110 366900060 PRIMER PUMP KIT/ NO CARB .................................. 1 ........INCLUDES ITEMS W/%
.................................................................................................S/N T-3424 AND ABOVE
111% 959028301 RETURN HOSE 3X6X600............................................ 1 ........ S/N T-3424 AND ABOVE
112% 954408170 HOSE CLIP 5 ............................................................... 2 ........S/N T-3424 AND ABOVE
113% 959021814 SPIRAL TUBE 6D-200L ............................................... 1 ........S/N T-3424 AND ABOVE
201 920212910 OPERATION DECAL 1
