IP8830 Broadworks IP Phone
User Guide
15 Dec. ‘08
Delayed Ring Timer (1)
0
Å
Clear
OK
08:30
Ring Setting
>2.Line 1 Configuration
Previous
Next
OK
Line 1 Configuration
>2.Delayed Ring Timer
Previous
Next
OK
Ringer Off
Current value is ‘No’.
es
No
o Dial 3, or move the cursor to 3.Phone Settings using the Previous-Next softkeys and press the
OK softkey.
o Dial 2, or move the cursor to 2.Ring Setting using the Previous-Next softkeys and press the OK
softkey.
o Dial the Line number plus one (2 for Line 1, 3 for Line 2,
etc.), or move the cursor to Line
n
Configuration using the
Previous-Next softkeys and press the OK softkey. The
value of
n
is the Line button number.
o Dial 2, or move the cursor to 2.Delayed Ring using the
Previous-Next softkeys and press the OK softkey. . Note
the line number is shown in parenthesis after “Delayed Ring
Timer”.
o Using the dial pad enter the desired delay up to 10 seconds
in one-second increments, zero is no delay. The
backspace softkey will delete the previous character and
the Clear softkey deletes the entire entry.
o Press the OK softkey to save your entry.
o Move to another parameter with the navigation buttons and continue the session or press the
Setting (
) button to exit the configuration session.
5.3. Ringer Off
The IP Phone can be programmed not to ring when an incoming call is received.
To set the Ringer Off parameter:
o Press the Setting (
) button.
o Dial 3, or move the cursor to 3.Phone Settings using the Previous-Next softkeys and press the
OK softkey.
o Dial 3, or move the cursor to 3.Ringer Off using the
Previous-Next softkeys and press the OK softkey.
o Press the Yes softkey to enable Ringer Off, or press the No
softkey to disable Ringer Off.
o Move to another parameter with the navigation buttons and continue the session or press the
Setting (
) button to exit the configuration session.
5.4. Enabling Automatic Headset Operation
Your IP8830 Phone supports use of a headset with a standard RJ-11 jack. In the Headset Auto Mode,
pressing a line button automatically connects audio to the headset. Also, redial, Speed dial, Speed
number dialing and click-to-call place calls with audio through the headset.
To enable Headset Auto Mode:
o Press the Setting (
) button.
o Dial 3, or move the cursor to 3.Phone Settings using the Previous-Next softkeys and press the
OK softkey.
o Dial 4, or move the cursor to 4.Headset Auto Mode using the Previous-Next softkeys and press
the OK softkey.
