2. Attach the sound unit to the monitor.

1. Attach the sound unit to the monitor. Place the sound unit under the monitor screen and insert the hook 1 on top

of the unit into the slot 1 located at the bottom rear of the monitor.

2. Slide the unit to the left until you hear it clicks. Then hook 2 will snap into slot 2.

NOTE

• To remove the sound unit from the monitor

At the rear of the monitor, hold the unit with both hands and slide the sound unit to the right and

pulling hook 2 out.
