0501S20000 8-2
MODEL 501 & 501-N PANINI GRILLE PARTS LIST
ITEM NO PART DESCRIPTION PART NUMBE
001 Platen-Single Lower Ribbed 0501-0002
001 Platen-Single Lower Smooth (Not Shown) 0501-0002-001
002 Heater-Tubular 1250W 208/220/240VAC 5730-2659
002 Heater-Tubular 1000W 115VAC 5730-2661
003 Plate-Lower Heater Holddown 0501-0012-001
004 Insulation 5501-7940
008 Cover-LH Spring 0501-0013-0012
010 Base-Small Single 0501-0001
013 Guide-Tube 0501-0014
016 Cover-Base Bottom 0501-0033
017 Tray-Grease 0501-0034
018 Scraper-Panini 0501-0035
019 Spacer-Bulb & Capillary Tube 0501-0037
020 Cover-Insulation 0501-0039
021 Insulation-Lower 5501-7946
024 Handle-Pull 5908-5135
025 Plate-Backing 0501-0038
102 Platen-LH Upper 9 X 9 Ribbed 0501-0003-0002
102 Platen-LH Upper 9 X 9 Smooth (Not Shown) 0501-0003-0012
103 Heater-Tubular 1000W 208/220/240VAC 5730-2658
103 Heater-Tubular 800W 115VAC 5730-2660
104 Plate-Heater Holddown 0501-0012
109 Tube-LH Conduit 0501-0004-0012
110 Ring-Retaining 5840-1128
111 Rod-Platen Pivot 0501-0005
112 Ring-E Clip 3/8” 5840-1275
113 Cover-Upper 9 X 9 Platen 0501-0006
116 Rod-LH Hinge 0501-0007-0002
117 Block-Drag 0501-0008
118 Ring-E Clip 1/2” 5840-1280
119 Spring-Torsion 7030-0028
124 Arm-Handle 0501-0009
126 Rod-Handle 0501-0010
127 Handle-Plastic 0501-0011
130 Stop-Top Platen 0501-0042
131 Screw-Wing M6 x 10 8841-9756
REV. 8/2/07
