General
Mute/Attenuation
ON: Press /[
MUTE
]. ( indicator lights.)
OFF: Press /[
MUTE
] again.
Note:
≥After turning off the ignition key, a security message is displayed, and the panel removable alarm that
reminds you to take the panel is activated. (When security function is set to on ➡ page 38)
≥Operations can be performed no matter which part of the touch panel is pressed BUT ONLY WHEN
THE POWER IS ON.
Volume
[VOL "]: Up
[VOL #]: Down
Setting range: 0 to 40
Open/Close the Front Panel
OPEN: Press [OPEN] on the front panel.
CLOSE: Raise the panel by hand.
: No sound.
Caution:
≥To avoid damaging the front panel, do not push
it down or place objects on it while it is open.
≥Do not pitch your finger or hand in the front
panel.
≥Do not insert foreign matter into the disc slot.
["] [#]
VOL (Volume)
[PWR]
(SOURCE)
[DISP]
(Display)
[MUTE]
["] [#]
(Hour/minute)
RANDOM
SCAN
REPEAT
Car Audio
PWR
DISP
NUMBER
123
456
789
0
DIM
BAND
RET
MENU
SET
SOURCE
FAC E
S • A
MUTE
VOL
RETURN
DIMMER
Power
Turn the key in the ignition until the accessory indicator lights.
∫ Power on
Press the touch panel on the main unit.
Press [PWR] (SOURCE) on the remote control unit.
∫ Power off
Press and hold on the main unit again for more than
1 second.
Press and hold [PWR] (SOURCE) on the remote control unit
again for more than 1 second.
SOURCE
1
Source
Press /(SOURCE) to change the source.
SOURCE
2
Note:
≥The sound level for each source is stored in
memory.
(There is one volume setting for AM radio
band, and one volume setting for FM radio
band.)
: Decrease the volume to
1
/
10.
Close
Clock Basics
The 12-hour system is used for the clock.
Initial Time
1 Press /[DISP] (display).
2 Press and hold /[DISP] (display) for
more than 2 seconds.
3 Press /["] or [#].
4 Press /[DISP] (display).
5 Press /["] or [#].
6 Press /[DISP] (display).
DISPLAY
DISPLAY
DISPLAY
DISPLAY
Note:
≥Press and hold /["] or [#]to
change numbers rapidly.
≥You can select the clock display during the unit
off. (➡ page 38)
(Hours blink.)
(Hours set.)
(Minutes blink.)
(Minutes set.)
(End.)
Decreasing volume range depends on setting.
(➡ page 38)
on
(Hour/minute)
(Volume)
(Power off)
VOL
MENU
OPEN
SOURCE DISPLAY
[VOL "] [VOL #]
[OPEN]
Touch panel
(Power on)
BAND
APM/
;
/
1
MOSFET
50W X 4
ST
Radio
CD player
CD changer control
AUX-IN setting
(When a CD is in the player.)
(When a CD changer is
connected and magazine is in
the changer.) ( page 28)
(Clock display)
Time Reset
Press and hold /[DISP] (display) for more
than 2 seconds to activate the time setting mode to
reset the time. Then, repeat steps 3 to 6.
DISPLAY
