3. Parts List
No. Parts No. Parts Name Q'ty Remark
D FFV7000168S Screw Assembly 1
Include Spring Washer&P.R Washer
E FFV7000079S Pan Tap Screw 4
F FFV7000097S Truss Tap Screw 2
G FFV7000018S Truss Tap Screw 2
H FFV7000175S Truss Tap Screw 7
I FFV7000170S Truss Screw 3
M FFV7000190S Truss Tap Screw 1
No. Parts No. Parts Name Q'ty Remark
41 FFV0790103S Casing 1
42 FFV5560012S Spring 1
43 FFV2810003S Joint 1
44 FFV1910108S Gear Motor Assembly 1
45 FFV1910104S Gear Motor Cover 1
46 FFV1940005S Damper 1
47 FFV2220055S Heater Holder 1
48 FFV5850029S Thermostat 1
49 FFV2220064S Heater Assembly 1
50 FFV3800003S Mesh 1
51 FFV2220065S Heater Cover 1
52 FFV5690022S Side Grille 2
J FFV7000198S Bind Tap Screw 2
K FFV7000192S Bind Tap Screw 8
L FFV7000039S Pan Tapping Screw 1
No. Parts No. Parts Name Q'ty Remark
53 FFV4650016S Poly Cover 1
54 FFV4340070S Operating Instructions 1
English,For CA Market/USA Market
55 FFV4340071S Operating Instructions 1
French,For USA Market
(55) FFV4340072S Operating Instructions 1
Spanish,For CA Market
56 FFV7000206S Screw Assembly 1
57 FFV4710354S Frame Foam L 1
58 FFV4650024S Poly Cover 1
59 FFV4710355S Frame Foam R 1
60 FFV9001043S Packing Case Assembly 1
Packing Section
Casing Section
Main Body Section
