Philips Multimedia Projector 18 English User guide cClear
Connecting to an external monitor
1 Connect the VGA Y connector marked ‘Projector’ (4a), of the VGA Y-cable supplied, to the
Data 2 socket of your projector.
2 Connect the VGA cable supplied (1a) between the computer and the VGA Y connector
marked ‘Computer’ (4b).
3 Connect the VGA Y connector marked ‘Monitor’ (4c) to the VGA cable (5) of the monitor.
4 Switch on your Computer, projector and external monitor.
The image projected is simultaneously shown on the monitor.
4. Installation >Connecting to a computer
Menu OK
AV
Mute
Source
Stand
by
Lamp
Temp
Menu OK
AV
Mute
Source
Stand
by
Lamp
Temp
LASERLASER
VOolumeVOolume
OKMenuMenu
StandbyStandby
OnOn
AV MuteAV Mute
SelectSelectModeModeSourceSource
MouseMouse RIGHTRIGHTLEFTLEFT
RIightRIightLeftLeft
6
