22
Unsupported formats:
Empty albums: an empty album is an •
album that does not contain MP3/
WMAles,andwillnotbeshownin
the display.
Unsupportedleformatsare•
skipped. For example, Word
documents(.doc)orMP3leswith
extension .dlf are ignored and not
played.
AAC,WAV,PCMaudioles•
DRMprotectedWMAles(.wav,•
.m4a, .m4p, .mp4, .aac)
WMAlesinLosslessformat•
Supported MP3 disc formats
ISO9660, Joliet•
Maximum title number: 511 (depending •
onlenamelength)
Maximum album number: 511•
Directory nesting up to a maximum of 8 •
levels
Supported sampling frequencies: 32 kHz, •
44.1kHz, 48 kHz
Supported Bit-rates: 32~256 (kbps), •
variable bit rates
ID3 tag v2.0 or later•
Maintenance
Clean the cabinet
Use a soft cloth slightly moistened with •
a mild detergent solution. Do not use
a solution containing alcohol, spirits,
ammonia or abrasives.
Clean discs
When a disc becomes dirty, clean it with •
a cleaning cloth. Wipe the disc from the
centre out.
General information
AC power 230 - 240V,
50Hz
Operation power
consumption 55W
Standby power consumption <2W
Eco Standby power
consumption <1W
USB direct Version 2.0/1.1
Dimensions
- Main Unit (W x H x D)
- Speaker Box (W x H x D)
220 x 292 x
285 mm
207 x 292 x
186 mm
Weight
- With Packing
- Main Unit
- Speaker Box
10.8 kg
4.3 kg
2 x 2.8 kg
USB playability information
Compatible USB devices:
USBashmemory(USB2.0or•
USB1.1)
USBashplayers(USB2.0or•
USB1.1)
memory cards (requires an additional •
card reader to work with this unit)
Supported formats:
USBormemoryleformatFAT12,•
FAT16, FAT32 (sector size: 512 bytes)
MP3 bit rate (data rate): 32-320 Kbps •
and variable bit rate
WMA v9 or earlier•
Directory nesting up to a maximum •
of 8 levels
Number of albums/ folders: •
maximum 99
Number of tracks/titles: maximum •
999
ID3 tag v2.0 or later•
File name in Unicode UTF8 •
(maximum length: 128 bytes)
EN
