SPECIFICATIONS
Specifications
AMPLIFIER
Output power .................... 2000 W PMPO / 2 X 50 W RMS
(1)
Signal-to-noise ratio ....................................≥ 75 dBA (IEC)
Frequency response......................... 40 – 20000 Hz, ± 3 dB
Input sensitivity
AUX/CDR In ......................................................... 500 mV
Microphone .......................................................... 4.5 mV
Output
Speakers ................................................................ ≥ 6 Ω
Surround Speakers ................................................ ≥ 6 Ω
Headphones............................................ 32 Ω – 1000 Ω
Subwoofer Out ........................... 1.5 V ±2dB, > 22000 Ω
Line Out .................................. 500 mV ±2dB, > 22000 Ω
(1) (6 Ω, 1 kHz, 10% THD)
DISC PLAYER
Number of programmable tracks ................................... 99
Frequency response..................................... 40 – 20000 Hz
Signal-to-noise ratio ............................................≥ 76 dBA
Channel separation ....................................≥ 79 dB (1 kHz)
Total harmonic distortion .......................... < 0.02% (1 kHz)
MPEG 1 ..................................................... VCD version 2.0
MPEG 1 Layer 3 (MP3-CD)............................ MPEG AUDIO
MP3-CD bit rate............................................. 32 – 256 kbps
sampling frequencies ................ 48 kHz, 44.1 kHz, 32 kHz
TUNER
FM wave range ......................................... 87.5 – 108 MHz
MW wave range (9 kHz) ............................ 531 – 1602 kHz
MW wave range (10 kHz) .......................... 530 – 1700 kHz
Tuning grid ............................................................ 9/10 kHz
Number of presets .......................................................... 40
Antenna
FM .................................................................. 75 Ω wire
AM ............................................................ Loop antenna
TAPE DECK
Frequency response
CrO
2
tape (type II) ..........................60 – 15000 Hz (5 dB)
Normal tape (type I) .......................60 – 15000 Hz (5 dB)
Signal-to-noise ratio
CrO
2
tape (type II) ............................................ ≥ 50 dBA
Normal tape (type I) ......................................... ≥ 47 dBA
Wow and flutter .............................................. ≤ 0.4% DIN
SPEAKERS
System .............................. 2-way; double port bass reflex
Impedance ................................................................... 6 Ω
Woofer .................................................................. 1 x 5.25"
Tweeter ................................................................... 1 x 2.5"
Dimensions (w x h x d) .....................240 x 310 x 315 (mm)
Weight ..............................................................3.9 kg each
GENERAL INFORMATION
Material/finish ..................................... Polystyrene/Metal
AC Power ........................................110 - 127 / 220 - 240 V;
.................................................... 50/60Hz; Switchable
Power Consumption
Active..................................................................... 75 W
Standby ............................................................... < 15 W
Dimensions (w x h x d) .....................265 x 310 x 390 (mm)
Weight (without speakers) ..................................... 7.38 kg
Subject to modification
