English
CONTROLS AND CONNECTIONS
Top and front panels
1 STANDBY/ON y . switches the set to standby/on
2 SOURCE. . . . . . . . selects the sound source for
CD/TUNER /CD RW /AUX;
switches on the set
Tuner:. . . . . . . . . selects waveband
3 PROGRAM
CD: . . . . . . . . . . . programs tracks and reviews the
program;
Tuner:. . . . . . . . . programs tuner stations manually or
automatically;
Timer:. . . . . . . . . activates, sets and deactivates the
timer function
4 CLOCK . . . . . . . . . sets the clock function
CD: . . . . . . . . . . . selects shuffle and repeat options,
e.g. repeats a track/ CD program/
entire CD;
plays tracks in random order
5 SOUND CONTROL
DBB. . . . . . . . . . . (Dynamic Bass Boost)
enhances the bass
DSC. . . . . . . . . . . (Digital Sound Control)
selects sound characteristics:
OPTIMAL/CLASSIC/JAZZ/POP
INCREDIBLE
SURROUND. . . . . creates a super-enhanced stereo
effect
6 Display. . . . . . . . shows the status of the set
7 VOLUME . . . . . . . adjusts the volume level and sound
settings;
adjusts the hour and minutes for the
clock/ timer functions
8 OPEN/CLOSE . . . . opens/ closes the CD tray
9 2; or PRESET 3 starts and pauses CD playback;
selects a preset tuner station (up);
9 or PRESET 4 . . stops CD playback or erase a CD
program;
activates/ deactivates demo mode;
. . . . . . . . . . . . . . selects a preset tuner station
(down);
0 2™, ¡1 or TUNING 3,4
CD: . . . . . . . . . . . fast searches back and forward
within a track;
skips to subsequent/ beginning of a
current track or previous track
Tuner:. . . . . . . . . (up, down) tunes to radio stations
Back panel
! p. . . . . . . . . . . . . 3.5 mm (16-150 Ω) stereo
headphone jack
@ AUX IN
RIGHT/ LEFT . . . . connects to the audio output of an
additional appliance
# SPEAKERS 6 Ω . . connects to the supplied speakers
$
LINE OUT
LEFT/RIGHT
. . . . . connects to the audio input of an
additional appliance
% DIGITAL OUT . . . . connects to a CD-(RW) system for
digital CD recording, or another
system for alternative sound output
^ Power cord . . . . . after all other connections have
been made, connect the power cord
to the wall outlet.
&
FM AERIAL 75
Ω . connects to the supplied antenna
wire or an antenna wall connection
* AM AERIAL . . . . . connects to the supplied AM frame
antenna
Remote control
y . . . . . . . . . . . . . . switches the set to standby
CD,TUNER,AUX,CDR . selects the respective sound source
TIMER . . . . . . . . . . . . activates and deactivates the timer
SLEEP . . . . . . . . . . . . activates and deactivates the
sleeper time;
selects sleeper time
DBB. . . . . . . . . . . . . . (Dynamic Bass Boost)
enhances the bass
DSC. . . . . . . . . . . . . . (Digital Sound Control)
selects sound characteristics:
OPTIMAL/CLASSIC/JAZZ/POP
INCR.SURR . . . . . . . . creates a super-enhanced stereo
effect
MUTE . . . . . . . . . . . . interrupts and resumes sound
reproduction
BAND . . . . . . . . . . . . selects waveband
NEWS/TA . . . . . . . . . not available on this version
VOLUME –, + . . . . . . adjusts volume level
2; . . . . . . . . . . . . . . starts/ pauses CD playback
¡, ™
CD: . . . . . . . . . . . . . . skips to the beginning of a current
track/ previous/ subsequent track;
Tuner:. . . . . . . . . . . . (down, up) selects a preset radio
station
9 . . . . . . . . . . . . . . stops CD playback or erases a CD
program
5, 6
CD: . . . . . . . . . . . . . . . .
searches backwards or forwards
within a track/CD;
Tuner: . . . . . . . . . . . . . .
(down, up) tunes to radio stations;
REPEAT . . . . . . . . . . . repeats a track/ CD program/
entire CD
SHUFFLE . . . . . . . . . . plays CD tracks in random order
PROGRAM
CD
:
. . . . . . . . . . . . . . programs tracks and reviews the
program;
Tuner
:
. . . . . . . . . . . programs radio stations or starts
Auto programming.
Notes:
• select the desired sound source first (e.g. CD,CD R),
then press the required function key (e.g. 2).
• the CD function keys on the remote control can be used
for a CD R.
