Specifications
AMPLIFIER
Output power.............................................. 2200 W PMPO
DPL Mode
Left/Right Channel ...........................2 x 75 W RMS
(1)
Center Channel ............................... 40 W RMS, 12 Ω
Surround Channel ....................... 2 x 20 W RMS, 6 Ω
Stereo mode .................. 2 x 75 W, 40 W, 2 x 20 W RMS
Signal-to-noise ratio....................................≥ 75 dBA (IEC)
Frequency response.........................40 – 20000 Hz, ± 3 dB
Input sensitivity
AUX/CDR In ......................................................... 500 mV
Microphone .......................................................... 2.5 mV
Output
Speakers................................................................ ≥ 6 Ω
Center Speaker.................................................... ≥ 12 Ω
SurroundSpeakers ................................................. ≥ 6 Ω
Headphones............................................ 32 Ω – 1000 Ω
Subwoofer Out ........................... 1.5 V ±2dB, > 22000 Ω
Line Out .................................. 500 mV ±2dB, > 22000 Ω
Digital Out ........................................... IEC 958, 44.1 kHz
(1) (6 Ω, 1 kHz, 10% THD)
CD PLAYER
Number of programmable tracks ................................... 40
Frequency response.....................................40 – 20000 Hz
Signal-to-noise ratio............................................ ≥ 76 dBA
Channel separation ....................................≥ 79 dB (1 kHz)
Total harmonic distortion .......................... < 0.02% (1 kHz)
TUNER
FM wave range........................................... 87.5 – 108 MHz
MW wave range (9 kHz) ..............................531 – 1602 kHz
MW wave range (10 kHz) ............................530 – 1700 kHz
Tuning grid ............................................................. 9/10 kHz
Number of presets............................................................40
Antenna
FM................................................................. 75 Ω wire
AM........................................................... Loop antenna
TAPE DECK
Frequency response
CrO
2
tape (type II) ..........................60 – 15000 Hz (5 dB)
Normal tape (type I) .......................60 – 15000 Hz (5 dB)
Signal-to-noise ratio
CrO
2
tape (type II) ............................................ ≥ 50 dBA
Normal tape (type I) ......................................... ≥ 47 dBA
Wow and flutter .............................................. ≤ 0.4% DIN
SPEAKERS
System ............... 3-way shielded; double port bass reflex
Impedance ....................................................................6 Ω
Woofer.................................................................... 1 x 6.5"
Tweeter................................................................... 1 x 2.5"
Polydome Tweeter ..................................................... 2 x 1"
Dimensions (w x h x d) .....................240 x 310 x 315 (mm)
Weight ..............................................................4.2 kg each
CENTER SPEAKER
System ................................................shielded bass reflex
Impedance ..................................................................12 Ω
Speaker Driver .......................................... 1 x 4” full range
Dimensions (w x h x d) .....................260 x 140 x 240 (mm)
Weight ...................................................................... 1.5 kg
SPECIFICATIONS
SURROUND SPEAKERS
System ....................................................... closed satellite
Impedance ....................................................................6 Ω
Speaker Driver .......................................... 1 x 4” full range
Dimensions (w x h x d) .....................234 x 103 x 224 (mm)
Weight ............................................................0.82 kg each
GENERAL INFORMATION
Material/finish ..................................... Polystyrene/Metal
AC Power
For Version /21-21M................110 – 127 / 220 – 240 V;
.................................................... 50/60 Hz Switchable
For Version /30................................. 230 – 240 V; 50 Hz
Power Consumption
Active................................................................... 145 W
Standby ............................................................... < 20 W
Standby (energy saving mode) .............................. < 2 W
Dimensions (w x h x d) ......................265 x 310 x 390 (mm)
Weight (without speakers) ....................................... 8.8 kg
Subject to modification
