1999 Apr 14 32
Philips Semiconductors Product specification
Audio processor with head amplifier for VHS hi-fi TDA9605H
8 LIMITING VALUES
In accordance with the Absolute Maximum Rating System (IEC 134).
9 THERMAL CHARACTERISTICS
10 GENERAL CHARACTERISTICS
SYMBOL PARAMETER CONDITIONS MIN. MAX. UNIT
V
CC
supply voltage 0 13.2 V
V
CCH
head amplifier supply voltage 0 5.5 V
T
stg
storage temperature −65 +150 °C
T
amb
operating ambient temperature 0 70 °C
V
es
electrostatic handling voltage machine model −300 +300 V
human body model −3000 +3000 V
I
lu(prot)
latch-up protection current on T
j
= 100 °C
pin HSMW −70 +100 mA
pin SDA −60 +100 mA
all other pins −100 +100 mA
SYMBOL PARAMETER CONDITIONS VALUE UNIT
R
th(j-a)
thermal resistance from junction to ambient in free air 60 K/W
SYMBOL PARAMETER CONDITIONS MIN. TYP. MAX. UNIT
Supplies
V
CC
supply voltage VCCS = 0 8.1 9 13.2 V
VCCS = 1 8.1 12 13.2 V
V
CCH
head amplifier supply voltage 4.75 5 5.5 V
I
CC
supply current standard operating mode − 36 48 mA
active standby (STBA = 1) − 812mA
passive standby (STBP = 1) − 46mA
I
CCH
head amplifier supply current playback mode − 21 28 mA
record-mute mode − 18 24 mA
record mode (HAC = 000) − 23 31 mA
record mode (HAC = 011) − 35 47 mA
record mode, (HAC = 111) − 67 89 mA
active or passive standby
(STBA = 1 or STBP = 1)
− 0 − mA
