Command Line Interface (CLI) AP-700 User Guide
Parameter Tables
211
TCP/UDP Port Filtering Table
The following parameters are used to configure TCP/UDP Port filters.
Alarms Parameters
SNMP Table Host Table Parameters
When creating table entries, you may either specifying the argument name followed by argument value. CLI applies
default values to the omitted arguments. Due to the nature of the information, the only argument that can be omitted is
the “comment” argument.
Name Type Value Access CLI Parameter
Port Filtering Table Table N/A R portflttbl
Table Index N/A User Defined
(there are also 4
pre-defined indices, see
Port Number below for
more information)
R index
Port Type Octet String tcp
udp
tcp/udp
RW porttype
Port Number Octet String User Defined
(there are also 4
pre-defined protocols:
Index 1: NetBios Name
Service - 137, Index 2:
NetBios Datagram
Service - 138, Index 3:
NetBios Session Service
- 139, Index 4: SNMP
Service - 161)
RW portnum
Protocol Name DisplayString User Defined
(there are also 4
pre-defined protocols,
see Port Number above)
RW protoname
Interface Bitmask Integer32 0 or 2 = No interfaces
(disable)
1 or 3 = Ethernet
4 or 6 = Wireless
5 or 7 = All interfaces
(default is 7)
RW ifbitmask
Status (optional) Integer enable (default for new
entries)
disable (default for
pre-defined entries)
delete
RW status
Name Type Value Access CLI Parameter
SNMP Trap Host Table Table N/A R snmptraphosttbl
Table Index Integer User Defined N/A index
IP Address IpAddress User Defined RW ipaddr
