REF PART�# DESCRIPTION REF PART�# DESCRIPTION
1 X1794001 AIR�REGULATOR 27 X1794027 TRIGGER�LEVER�2
2 X1794002 BORE�BRUSH 28 X1794028 TRIGGER�LEVER�1
3 X1794003 BAFFLE��WRENCH 29 X1794029 LOCKING�SPRING
4 X1794004 TOOL�WRENCH 30 X1794030 PAINT�NEEDLE�WASHER
5 X1794005 AIR�INLET�JOINT 31 X1794031 DIRECTION�SCREW
6 X1794006 RETAINER 32 X1794032 BAFFLE�WASHER
7 X1794007 O-RING�6�X�2 33 X1794033 BAFFLE
8 X1794008 PATTERN�ADJ�SCREW 34 X1794034 FLUID�NOZZLE�1.4MM
9 X1794009 SPECIAL�WASHER 35 X1794035 ATOMIZATION�CAP
10 X1794010 PATTERN�ADJ�KNOB 36 X1794036 FLUID�CAP�WASHER
11 X1794011 PATTERN
�ADJ 37 X1794037 CAP�NUT
12 X1794012
FLAT�HEAD�SCREW 38 X1794038 PIN�SPRING��
13 X1794013
FLUID�ADJ�KNOB 39 X1794039 DIRECTION�SCREW
14 X1794014 SEALING
�CUP 40 X1794040 SPECIAL�WASHER
15 X1794015 FLUID�NEEDLE�SPRING 41 X1794041 O-RING�8.5�X�1.2
16 X1794016
FLUID�ADJ�NEEDLE 42 X1794042 SWITCH�KNOB
17 X1794017 HOOK 43 X1794043 AIR�VALVE�BODY
18 X1794018
FLUID�INLET�JOINT 44 X1794044 SWITCH�SPRING
19 X1794019 INLET
�WASHER 45 X1794045 AIR�INLET�VALVE
20 X1794020
FILTER 46 X1794046 AIR�VALVE�SPRING
21 X1794021 CUP
�600ML 47 X1794047 SPECIAL�WASHER
22 X1794022 CUP�COVER 48 X1794048 O-RING�2.5�X�2.1
23 X1794023 VENTILATOR
�HEAD 49 X1794049 AIR�ADJUSTMENT�KNOB
24 X1794024 RETAINER�4MM 50 X1794050 AIR�ADJUSTMENT�SCREW
26 X1794026 TRIGGER 51 X1794051 O-RING�KIT
