Settings and Adjustments
Menus (Push MAIN MENU) Parameters (Turn MENU) Range (Turn +/–) Description
<SURROUND> SURR. EFFECT 100% From 0 to 150% (in 5% steps) Page 34
WALL S____|____H 17 step
REVERB S____|____L 17 step
BASS +0 dB ------- From –10.0 to +10.0 dB (in 1 dB steps) Page 34
BASS ??? Hz ------- From 99 to 1 kHz (in 21 steps)
MID +0 dB ------- From –10.0 to +10.0 dB (in 1.0 dB steps)
MID [WIDE] ------- WIDE, MIDDLE, NARROW
MID ??? Hz ------- From 198 Hz to 10 kHz (in 37 steps)
TREBLE +0 dB ------- From –10.0 to +10.0 dB (in 1.0 dB steps)
TREBLE ??? Hz ------- From 1.0 to 10 kHz (in 23 steps)
<LEVEL> TEST TONE [LS] auto OFF, AUTO, L, C, R, RS, LS, SW Pages 35~36
FRONT L____|____R 17 step (in 0.5 dB steps)
REAR L____|____R 17 step (in 0.5 dB steps)
CENTER LEVEL – 0 dB From +10.0 to –20.0 dB, OFF (in 0.5 dB steps)
REAR LEVEL – 0 dB From +10.0 to –20.0 dB, OFF (in 0.5 dB steps)
SUB WOOFER – 0 dB From +10.0 to –20.0 dB, OFF (in 0.5 dB steps)
LFE MIX – 0 dB From +0.0 to –20.0 dB, OFF (in 0.5 dB steps)
D. RANGE COMP STD OFF, 0.1 - - - 0.9, STD, MAX
DIALOG TRIM +0.0 dB From +5.0 to –5.0 dB (in 0.5 dB steps)
SURR TRIM +0.0 dB From +5.0 to –5.0 dB (in 0.5 dB steps)
MUTING [OFF] OFF, ON
VOLUME –000 dB 0 - - - -100 dB, –∞ dB (min. 0.5 dB step)
<CUSTOMIZE> V. PROCESSOR [OFF] OFF, ON Page 38
V: (video source) A: (audio source)
AU INPUT [ANALOG] AUTO, OPTICAL, COAXIAL, AC-3 RF, ANALOG
DECODE MODE [AC-3] AUTO, AC-3, DTS, MPEG
DISP. DIMMER [100%] 100 - - - 25% (in 1% steps)
OUTPUT LEVEL [NORM] NORM, LOW
AUTO FUNCTION [ON] ON, OFF
MEMORY CLEAR [YES] NO, YES Page 38
SLEEP 0:00:00 2:00:00, 1:30:00, 1:00:00, 0:30:00, OFF Page 38
