Protects sensitive networking equipment from blackouts, voltage fluctuations and transient surges
Line Interactive Automatic Voltage Regulation (AVR) corrects 208V nominal input from 167 to 260VAC back to usable 208/120V levels
without consuming battery power
AVR circuits boost undervoltages by 12% and reduce overvoltages by 12%
Network interfaces support simultaneous communications via USB, DB9 serial and SNMPWEBCARD slot
Included PowerAlert UPS monitoring software supports safe unattended shutdown, monitoring and control via local connected servers, plus
any number of additional servers over IP
Communications ports support on-battery, low-battery, power-restored, AC-voltage, DC-voltage, output current monitoring, battery charge
current, battery capacity, internal UPS temperature, AC line frequency, timed inverter shutoff, activate self-test and load bank output power
control
Built-in Emergency Power Off (EPO) interface with cable
Sine wave output in AC and battery mode
Expandable runtime with optional BP48V60RT3U external battery packs
Half/full load runtime of 27/10 minutes with internal batteries
Includes 11 output receptacles (2 L6-20, 1 L6-30 & 8 NEMA 5-15/20R)
Ships with installed L6-30P input plug, supports user supplied 50A replacement plug or hardwire input
Integrated 8 bank switched PDU enables remote outlet management for load shedding or remote reboot of individual devices
3 stage metered LEDs offer current monitoring and battery charge level
Mains power and voltage regulation LEDs offer at-a-glance power status information
Front panel switches support self-test and alarm cancel functions
Included adjustable mounting rails support installation in 4 post 19 inch racks
UPS ships fully assembled in full compliance with DOT regulations, no time consuming connection of internal batteries by user is required
Supports 2 post rackmount installation with optional 2POSTRMKIT accessory
Supports upright tower placement with optional 2-9USTAND accessory
UL (USA), cUL (Canada), NOM (Mexico), TUV, FCC Class A (Emissions) listed
2 year manufacturer's product warranty, $250,000 Ultimate Lifetime Insurance
Specifications
SYSTEM OVERVIEW
Voltage compatibility 208V
Frequency
compatibility
60Hz
OUTPUT
Output VA 5000
Output watts 3750
Output nominal
voltage
208V & 120V
Output voltage
regulation
LINE MODE: Sine wave line voltage 208V & 120V (+/-10%) BATTERY MODE: 208V & 120V (+/-5%)
Output frequency
regulation
LINE MODE: Passes line frequency of 60Hz +/-10%, BATTERY MODE: Inverter output regulated to 60Hz (+/-0.5Hz)
Outlet quantity / type 1 NEMA L6-30R, 2 NEMA L6-20R and 8 NEMA 5-15/20R
Customized load
management
receptacles
Includes 8 single-outlet NEMA 5-15/20R load banks that support on-demand load shedding and remote reboot of locked
network devices. Controllable via PowerAlert software to switch off optional loads, e.g. monitors, to increase available
runtime for servers and other critical devices
Overload protection Resettable circuit breakers
INPUT
Maximum input
amps
27A
Input connection
type
NEMA L6-30P
Input cord length 10 ft./3m
Recommended
Electrical Service
208V 30A or optional 208V 50A input supported
