563701 MaxMover (FP DMX)
OR
563700 + 563704
Added value - ARRI MaxMover
Function overview
• Adjustable width design (6-24kW ARRI Lampheads)
• Max. weight load 80kg/176lb
• Universal adapter with quick snap in function
• Adjustable slipping clutches (Pan, Tilt) 0-80Nm
• Calibration-free, absolute position determination
• Calibration function for focus drive to realise a dynamic resolution
of the focus travel, allows the operation of various lampheads
• Position sensor (hanging or standing operation)
• 0,35° movement resolution, 10 bit (mechanical)
• 16 bit D/A-converter (8 bit/16 bit DMX control)
• DMX profiles available (download www.arri.com)
• Control options:
- Analog control (standard)
- Basic DMX control (optional), incl. DMX testing functions
- Fully programmable DMX position control (optional),
incl. DMX testing functions
- Fully programmable wireless DMX position control (optional)
• CE conformity
• Control options: IP54
• Control options: Protection class 1
• Control options: Electrically isolated control interfaces
• Control options: Independent mechanical stress testing certificate
• Wide range line input (90-265VAC 50/60Hz)
Added value - ARRI MaxMover
Design features
• High quality industry standard servo motors (brushless)
• Separable bearings (Pan / Tilt) for extreme axial mechanical stress
• 35mm axial drive
• High quality special aluminium castings, high precise milled
• High precision grinded stainless steel pipes (supporting
structure)
• High precision worm gear transmission (Pan / Tilt)
• High precision ginded, hardened worm gear transmissions
• High precision milled aluminium attachements
• High precision trapezoidal thread spindle (adjustable width
function)
• Self-lubricating maintenance free brass bearings (Pan / Tilt)
• Polymeric bush bearing (adjustable width function)
• Seamless high precision stainless steel pipe (adjustable width
function)
Example DMX Console
(not an ARRI product)
Example Wireless DMX
FP DMX Converter
Example DMX Pocket Console
(not an ARRI product)
563700 MaxMover
(Standard analog)
563710 Basic DMX Converter
(not an ARRI product)
System Overview – Setup 4 (Wireless DMX setup)
Wireless DMX systems may be used with Basic and FP operation with DMX!
