MODEL WBV21DZ
OPERATING YOUR WINE & BEVERAGE CENTER
It is recommended you install the appliance in a place where the ambient temperature is between 72-
78 degrees Fahrenheit. If the ambient temperature is above or below recommended temperatures,
the performance of the unit may be affected. For example, placing your unit in extreme cold or hot
conditions may cause interior temperatures to fluctuate. The range of 40-65 degrees Fahrenheit may
not be reached.
Recommended Temperatures for Chilling Wine.
Red Wines
58 - 65 ºF
14 - 18 ºC
Dry / White Wines
48 - 57 ºF
10 - 13 ºC
Rose Wines
49 - 51 ºF
9 – 11 ºC
Sparkling Wines
40 - 47 ºF
5 - 8 ºC
Wine Chiller (Left Side / Zone) Control Panel
Beverage Center (Right Side / Zone) Control Panel
ON/OFF POWER
To turn ON or OFF the appliance, press the button/mark and hold for 3 seconds.
Temperature Ranges by Side / Zone
WINE Chiller (LEFT SIDE)
45º - 65º F
7º - 18º C
BEVERAGE COOLER (RIGHT SIDE) 34º - 43º F 1º - 6º C
You can select temperature display setting from Fahrenheit to Celsius degree by pushing the ºF/ºC
button/mark. Fahrenheit or Celsius degrees indicator will appear in blue color in the temperature
display window for each zone.
