Congratulations on your purchase of a new Level Command
kit. This kit was designed to provide inflation control of your
air helper springs. This kit will be an asset to your vehicle,
meeting nearly all of your air supply needs.
Please take a few minutes to read through the instructions,
identify the components, and learn how to properly install your
Level Command kit.
N
OTE
:
The Level Command kit can be used with all air helper
spring products. If you are installing an air suspension system,
do not install the air line tubing to the air springs as stated in
the suspension system instruction manual. If you are adding
the Level Command kit to an existing air suspension system,
you will need to deflate the air springs and remove the air line
tubing.
N
OTE
ON
C
ONNECTING
THE
AIR
LINE
TUBING
:
Cut the air line tubing as squarely as possible. To connect
the air line tubing to the fittings, push the tubing into the fittings
as far as possible. If for any reason the tubing must be removed,
first release the air pressure from the air helper spring. Push the
collar toward the body of the fitting and the pull out the tubing.
To reassemble, make sure the tubing is cut squarely and push
the tubing back into the fitting.
T
OOLS
REQUIRED
:
• 3/16"
DRILL
BIT
• 3/8"
DRILL
BIT
• 1/4"
DRILL
BIT
• P
OWER
DRILL
• W
IRE
CRIMPER
/
STRIPPER
• P
LIERS
• P
HILLIPS
SCREW
DRIVER
• U
TILITY
KNIFE
• (2) 7/16"
WRENCHES
• C
ENTER
PUNCH
0 150
30
120
60 90
200
400
600
800
1000
psi
kPa
PSI
SINGLE AIR CONTROL PANEL 1
COMPRESSOR 9210 1
30 FT. AIR LINE TUBING 1
1/8" NPT PUSH-TO-CONNECT
STRAIGHT FITTING 3055 1
PUSH-TO-CONNECT
T-FITTING 3025 2
10 -32 x 1" MACHINE SCREW 5
10 -32 LOCK NUT 5
24-8204 03-01 NAD-30665-2
2097 / 2187 / 2227 / 2233
P
ARTS
LIST
L
EVEL
C
OMMAND
#10 FLAT WASHER 7
15 FT. 16 GAGE WIRE 1
IN-LINE FUSE HOLDER 1
20 AMP BLADE FUSE 1
FEMALE SPADE CONNECTOR 2
MALE SPADE CONNECTOR 1
RING TERMINAL 1
WIRE CONNECTOR 2
NYLON TIE 15
L
EVEL
C
OMMAND
WITH
9210 C
OMPRESSOR
