AIR SPRING
(sold separately)
0 150
30
120
60 90
200
400
600
800
1000
psi
kPa
PSI
AIR SPRING
(sold separately)
“T” FITTING
Male spade connector
Femal spade connector
Inline fuse connector
Wire connector
Air Line & Wiring Diagram
FUSE
GROUND
AIR LINE
AIR LINE
Connectors:
Ring Terminal
RED
WHITE
WHITE
10/32 LOCK NUT
#10 FLAT WASHER
VEHICLE PANEL
Compressor Attachment
AIR COMPRESSOR
1” MACHINE
SCREW
BRASS
INSERTS
RUBBER
ISOLATORS
1/4 HOLES TO
BE DRILLED
STRAIGHT AIR FITTING
POSITIVE, 12 VOLT
DASHBOARD
ILLUMINATION
CIRCUIT
Figure “A”
2227
12 VOLT, 20 AMP
MINIMUM IGNITION
ACTIVATED CIRCUIT
BLACK (TO GROUND)
