-7-
The numbering of the product features shown
refers to the illustration of the tool on the
graphic page 2.
1 Exit opening for laser beam
2 Automatic levelling indicator
3 On/Off switch
4 Latch of battery lid
5 Battery lid
6 Contact surface
7 Laser warning label
8 Tripod mount 1/4"
9 Protective case
10 Laser viewing glasses*
11 Tripod*
*The accessories illustra
ted or described are
not included as standard delivery.
Features
Working range
– Standard . . . . . . . . . . . . . . . . . . 30ft (10m)
Levelling Accuracy . . . . . . . ±7/32-in at 30-ft
(±5mm at 10m)
Self-levelling range,
typically . . . . . . . . . . . . . . . . . . . . . . . . . ±4°
Levelling duration,
typically . . . . . . . . . . . . . . . . . . . . . . . . . . .4 s
Operating temperature . . . . . . 41°F ~104°F
(+5°C ~+40°C)
Storage temperature . . . . . . . . .-4°F ~158°F
(–20°C ~+70°C)
Relative air humidity,
max. . . . . . . . . . . . . . . . . . . . . . . . . . .90 %
Laser class . . . . . . . . . . . . . . . . . . . . . . 2
Laser type . . . . . . . . . . . . . . .635 nm, <1mW
Tripod mount . . . . . . . . . . . . . . . . . . .1/4-20
Batteries . . . . . . . . . . . . .2 x 1.5 V LR6 (AA)
Operating lifetime, approx. . . . . . . . . . . .15 h
Weight . . . . . . . . . . . . . . . . . 0.88 lb (0.4kg)
Dimensions . . . . . . . .4-1/4” x 2-5/8
” x 3.5/8”
(108x 66 x 92mm)
Please observe the article number on the
type plate of your tool. The trade names of
the individual tools may vary.
Technical Data
Inserting/Replacing the Battery
Use only alkaline batteries.
To open the battery lid 5, press on the latch 4
and fold the battery lid up. Insert the
batteries. When inserting, pay attention to
the correct polarity according to the
representation on the inside of the
battery compartment.
Always replace all batteries at the same time.
Only use batteries from one brand and with
the identical capacity.
• Remove the batteries from the
tool when not using it for extended
periods. When storing for extended
periods
, the batteries can corrode and
discharge themselves.
The tool is intended for determining and checking horiontal and vertical lines.
The tool is suitable exclusively for operation in enclosed working sites.
Intended Use
Preparation
