138 DON’T FORGET - THERE’S NO MINIMUM ORDER AT CPC!
260mm Table Top
Mitre Saw
Model: DW711-GB
Powerful dust protected induction motor,
provides years of maintenance free service
Integrated blade brake
Integrated positive mitre stops at 15°, 25°, 30°,
45°, quick release mitre mechanism
up to 48°
Large adjustable scratch-resistant scale
Large adjustable parallel table top fence
can be used on both sides of the blade
Effective 3 port dust extraction facility
Supplied with 260mm SERIES 40® 24 tooth TCT blade,
top guard with extraction, blade spanner, allen key, push stick
497819
254mm Sliding Mitre
Saw with Laser
Model: EMS-2026SCL
Exact line laser for improved accuracy
when cutting
Quick action mitre lock handle for faster
mitre settings
Extra wide side extensions to
support wider timber
Built in spindle lock for easy single wrench blade change
9 pre-set index angles
Contents: 1x 40 tooth TCT blade, 2x Extensions, 1x Dust bag, 1x Wrench
480375
Voltage: 240V; No Load Speed: 2750rpm; Saw Blade Dia: 260mm; Bore
Size: 30mm; Mitre Capacity: 48°; Dimensions (LxHxD): 490 x 620 x
590mm; Weight: 24kg
Mitre Saw: 45°/45° Cutting Capacity: 90 x 20mm, 90°/90° Cutting
Capacity 125 x 55mm / 140 x 40mm
Table Saw : Cutting Depth: 50mm
£305.98
order code TL0881608
Voltage: 240V; No Load Speed: 4500rpm; Saw Blade Dia: 254mm;
Bore Size: 25.4mm; 90° Cutting Depth: 90 x 305mm; 45° Cutting
Depth: 90 x 115mm
£183.49
order code TL1185308
205mm Table Saw
Model: NPE720
24 teeth Tungsten
Carbide Tipped blade
Adjustable table
466753
£48.47
order code TL1074108
Parallel fence
Mitre guide
Voltage: 230V; No Load Speed: 2800rpm;
Saw Blade Dia: 205mm; Bore Size: 15.9mm;
90° Cutting Depth: 43mm; 45° Cutting
Depth: 28mm; Table Size: 400 x 513mm
12" Mitre Saw
Model: GCM 121 & 122
Max cutting depth up to 104 mm, cutting
width up to 196 mm
Mitre angle can be set up to 52° on
the left and 52° on the right
Swivelling saw head for inclined cuts
up to 47° left
Integrated carrying grip for
easy transport
Contents: 1 x Saw blade, 1 x
Quick action clamp, 1 x Dust
extraction bag, 1 x Insert plate, 1
x Dust extraction adapter
498000
TL1179308 240V £245.97
TL1179208 110V £249.90
Wattage 240V: 1800W; Wattage 110V: 1450WVoltage: 240V or 110V;
No Load Speed: 4300rpm; Saw Blade Dia: 305mm; Bore Size: 30mm;
Max.Bevel: 47°L; Mitre Capacity: 52°L / 52°R; Dimensions (LxHxD):
670 x 640 x 720mm; Weight: 20.5kg
254mm Table Saw
Model: NPE1600
24 teeth Tungsten Carbide Tipped blade
Adjustable table
Electric brake
Parallel fence
Mitre guide
497920
Voltage: 230V; No Load Speed:
4800rpm; Saw Blade Dia:
254mm; Bore Size: 25.4mm;
90° Cutting Depth: 80mm; 45°
Cutting Depth: 55mm; Table
Size: 430 x 640mm
£88.17
order code TL1074208
254mm Table Saw
Die-cast table with steel extension
tables
Mitre gauge allows precise angle to
be cut quickly and easily between
+60° and -60°
Lightweight for easy portability
Adjustable height and angle settings
Complete with floor stand and
strong durable rubber feet for
stability
Contents: 1 x 40 tooth TCT blade, rip
fence, mitre gauge, push stick, wrench
Model: ETS-1526AL
480422
£125.10
order code TL1185408
