CALL OUR CUSTOMER HOTLINE FOR ALL ORDERS AND ENQUIRIES ON 08701 20 25 30 23
All Prices Exclude VAT
Technical Data
Impedance
75Ω
Conductor 1/1.00mm
Screen 48/0.12mm Braided Copper Screen
Dielectric Semi Air-Spaced PE
Outer Diameter 6.50mm
CSA (mm) 0.78
A 75Ω, low loss television downlead available in both white and
brown. The cable has a 1.00mm single conductor and an overall PVC
sheath.
Technical Data
Impedance
75Ω
Conductor 1/1.00mm
Screen 64/0.12mm Braided Copper Screen + Aluminium Foil
Outer Diameter 6.50mm
CSA (mm) 0.78
1+ 3+
CBBR012508 Black 100m £11.98 £9.98
CBBR202008 Black 250m £27.78 £26.39
CBBR012608 Brown 100m £11.45 £9.98
CBBR012708 White 100m £9.44 -
CBBR202108 White 250m £27.78 £26.39
RG6U 75Ω
Satellite Cable
A 75Ω coaxial cable designed for satellite interconnection purposes.
The cable has a 1.00mm conductor and a five cell semi air spaced
dielectric.
462470
Technical Data
Inner conductor nominal diameter
1.00mm bare copper
Dielectric nominal Diameter 4.60mm
Outer Conductor Nom. Diameter 4.65mm
Screen
64/0.12mm Braided Copper
Screen (54% coverage)
Nominal O/D
6.65mm
Max. Bending Radius Single Bend/
Multiple Bending
40mm / 70mm
Conductor Resistance - inner
21.50Ω
- Outer
14.9Ω
Nominal Characteristic Impedance
75Ω
Attenuation Loss (dB/100m)
5 50 100 200 460 860 100 1750 2150
MHz MHz MHz MHz MHz MHz MHz MHz MHz
1.45 4.32 6.20 9.00 14.9 19.32 21.27 28.57 32.03
Semi Air Spaced Dielectric
1+ 3+
CBBR671708 Black 50m £12.86 £12.25
CBBR671808 Black 100m £24.68 £24.31
CBBR671908 Black 250m £69.25 £66.31
CBBR672108 White 100m £24.68 £24.31
CBBR672208 White 250m £74.58 £69.85
CBBR672408 Brown 100m £31.33 £29.54
Foam Filled Dielectric
CBBR672608 Black 50m £12.86 £12.25
CBBR672708 Black 100m £29.86 £28.49
CBBR673008 White 100m £26.05 £25.35
A range of coaxial cables, suitable for the
reception of digital terrestrial and digital
satellite reception as well as high speed data transfer. The
cable conforms to BS EN 50117-1 and RNE678/100-04 thus
making it fully approved for digital installations. Designed and
manufactured to minimise signal losses and to provide
excellent RLR characteristics up to 1800MHz. The cable is
available with either semi air spaced or foam filled
dielectric, 64 strand copper braid and copper foil. Available
in black, white and brown the cable is supplied in lengths
of 50m, 100m and 250m.
• Certified to BS EN 50117-1, RNE678/100-04
456214
BSkyB Endorsed Satellite Cable
Technical Data CW1308F
Pair No. 'A' Wire 'B' Wire
1 WHITE/Blue
BLUE/White
2 WHITE/Orange ORANGE/White
3 WHITE/Green GREEN/White
4 WHITE/Brown BROWN/White
5 WHITE/Grey GREY/White
6 RED/Blue BLUE/Red
1+ 5+
CBBR910008 2 Pair £6.12 £5.85
CBBR910508 2 Pair £14.45 £13.25
CBBR910608 2 Pair £29.63 £28.35
CBBR910708 2 Pair £9.98 £9.25
CBBR910108 3 Pair £5.98 £5.45
CBBR910808 3 Pair £23.58 £22.35
CBBR911008 3 Pair £11.45 £11.03
CBBR910208 4 Pair £10.79 £10.35
CBBR911208 6 Pair £30.29 £27.64
Low Smoke & Fume (LSF)
CBBR998608 2 Pair £9.25 £8.24
CBBR998708 3 Pair £15.84 £14.86
CBBR998808 4 Pair £20.82 £19.79
CBBR998908 6 Pair £26.43 £25.33
External Use
CBBR531308 5 Pair £47.25 £45.03
CBBR531408 10 Pair £60.39 £59.25
CBBR531508 20 Pair £129.38 £116.76
• Max. Current per Core 0.25 A
• Nom. Conductor Area 0.20mm
• Max . Working Voltage 80V
• To BT Spec CW1308F
• White
• 100m Reel
Telephone Cable, 100m Reel
456225
75Ω Low Loss Coaxial
Cable
250m Reels
1+ 3+
CBBR012308 Brown 100m £8.45 £7.96
CBBR202208 Brown 250m £30.45 £27.05
CBBR012408 White 100m £8.45 £7.96
CBBR202308 White 250m £30.45 £27.05
£5.45
An internal cable designed for
interconnection of communication
equipment. The cables range from
2 Pair (4 Core) to 6 Pair (12 Core).
464987
