If the indicator lights are “OFF”, the charger
is not receiving power from power supply
outlet.
If the green indicator light is
“BLINKING”, the battery
pack is being fast-charged.
Fast-charging will automatically stop when
the battery pack is fully charged.
If the green indicator light is
"ON", the charger is
plugged in but the battery
pack is not inserted, or the battery pack is
fully charged, or the battery pack is too hot or
cold for fast-charging. The charger will
automatically switch to fast-charging once a
suitable temperature is reached.
-11-
BATTERY
PACK
CHARGER
RED LIGHT
GREEN LIGHT
FIG. 5
The lithium ion battery is protected against
deep discharging by the “Electronic Cell
Protection (ECP)”. When the battery is empty,
the tool is switched off by means of a
protective circuit.
The battery is supplied partially charged.
Completely charge the battery before using
your cordless screwdriver for the first time.
The lithium ion battery can be charged at any
time, without reducing its service life.
Interrupting the charging procedure does not
damage the battery.
Plug charger cord into your standard power
outlet, then insert battery pack into charger
(Fig. 6).
The charger’s green indicator light will begin to
“BLINK”. This indicates that the battery is
receiving a fast charge. Fast-charging will
automatically stop when the battery pack is
fully charged.
When the indicator light stops “BLINKING”
(and becomes a steady green light) fast
charging is complete.
The battery pack may be used even though
the light may still be blinking. The light may
require more time to stop blinking depending
on temperature. When you begin the charging
process of the battery pack, a steady green
light could also mean the battery pack is too
hot or too cold.
""$ "##) #9./6
"$$")!9./6
