Replacement Parts List HL550200, HL550700
Ref
No. Description Part No. Qty.
Ref
No. Description Part No. Qty.
1 Pump HL300001AV 1
2 Screw M8-1.25 x 40 mm ▼ 4
3 Lock washer M8 ▼ 4
4 Screw M4.2 x 10 mm ■ 4
5 Screw M6-19 mm ● 4
6 Motor shroud HL011200AV 1
7 Pump shroud HL011100AV 1
8 Handle grip HL014700AV 1
9 Tank AR054300BL 1
10 Exhaust tube (includes 2 nuts and
2 ferrules) ▲ 1
11 Check valve CV307800AV 1
12 Grommet HL015400AV 1
13 Foot ◆ 4
14 Screw M8-1.25 x 15 mm ◆ 4
15 1/4 inch Unloader tube HL016000AV 1
16 Regulator - 1/4 inch NPT RE206202AV 1
17 Pressure switch - 1/4 inch NPT CW212300AJ 1
18 Pressure gauge - 1/4 inch 0-250 psi GA016306AV 2
19 Safety valve - 1/4 inch NPT V-215100AV 1
20 Pipe nipple - 1/4 inch NPT,
2 Inches long HL015900AV 2
21 Electric cord EC014500AV 1
22 Unloader valve CW212400AV 1
23 Bushing ST071407AV 1
24 Easy start valve assembly HL010900AV 1
25 Tee fitting HL009900AV 1
26 Drain valve - 1/4 inch NPT
(Not shown) D-1403 2
27 Strain relief CW212800AV 2
REPLACEMENT PARTS KITS
▲ Exhaust tube kit HL014900AV
■ Pump shroud screw kit HL012800AV
● Motor shroud screw kit HL012900AV
◆ Rubber feet kit HL015100AV
▼ Pump mounting kit HL015200AV
Δ Decal kit HL015600AV
Δ Not shown
For Replacement Parts or Technical Assistance,
Call 1-800-543-6400
Please provide following information:
- Model number
- Serial number (if any)
- Part description and number as shown in parts list
Address parts correspondence to:
Attn. Customer Service
100 Production Drive
Harrison, OH 45030
2
