Replacement Parts List HL300001AV
Ref
No. Description Part No. Qty.
Ref
No. Description Part No. Qty.
1 Socket head cap screw
M6-1.25 x 110 mm - cylinder head ▲ 4
2 Lock washer M6 ▲ 4
3 Flat washer M6 ▲ 4
4 Self-tapping Phillips head screw
3.5 mm OD x 12 mm ■ 1
5 Air filter retainer clip ■ 1
6 Air filter ■ 1
7 Air filter screen ■ 1
8 Cylinder head HL007600AV 1
9 Head gasket ● 1
10 Valve plate ● 2
11 Center valve gasket ● 1
12 Valve ● 2
13 Cylinder gasket ● 1
14 Roll pin XC5.4 mm x 7 mm -
valve plate ● 2
15 Cylinder HL007500AV 1
16 Compression ring ◆ ▼ 2
17 Oil control ring ◆ ▼ 1
18 Piston ▼ 1
19 Wrist pin ▼ 1
20 Wrist pin retainer ▼ 2
21 Connecting rod ▼ 1
22 Dipstick assembly with o-ring HL012000AV 1
23 Socket head cap screw
M4-1.25 x 14 mm - front cover † 4
24 Crankcase front cover † 1
25 Oil drain with o-ring -
M5-1.25 x 10 mm HL012100AV 1
26 Crankcase cover gasket HL009100AV 1
27 SHCS M8-1.25 x 25 mm
L.X. thread - eccentric ‡ 1
28 Eccentric counter weight ‡ 1
29 Bearing - pump crankcase †† 1
30 Oil seal 20 mm x 35 mm x
7 mm - crankcase †† 1
31 Cylinder o-ring 65 mm x 2.65 mm ● 1
32 Crankcase †† 1
33 Motor run capacitor †† HL008500AV 1
34 Motor †† 1
35 Motor bearing †† 1
36 Motor bearing retainer †† 1
37 Motor rear end bell frame †† 1
38 Motor fan ††, ‡‡ 1
39 Hex head cap screw
M5 - 1.25 x 11.5 mm - motor bolts †† 4
40 Flat washer M5 †† 4
41 Lock washer M5 †† 4
42 Lock washer serrated 14.5 x 24 mm ††, ‡‡ 1
43 Flat washer - M8 ††, ‡‡ 1
44 Hex head cap screw
M8 - 1.25 x 30 mm - fan bolt ††, ‡‡ 1
45 Self tapping Phillips head screw
4.2 x 10 mm (screw kit) HL012800AV 4
46 Pump head shroud HL011100AV 1
47 Motor shroud HL011200AV 1
48 Self-tapping Phillips head screw
M6 - 19 mm (screw kit) HL012900AV 4
REPLACEMENT PARTS KITS
▲ Pump cylinder bolt kit HL011500AV
■ Filter/screen kit HL011600AV
● Valve plate/gasket kit HL011700AV
◆ Ring kit HL011800AV
▼ Piston assembly HL011900AV
† Crankcase cover kit HL012200AV
‡ Eccentric kit HL012300AV
†† Motor kit HL012400AV
‡‡ Motor fan kit HL012500AV
For Replacement Parts or Technical Assistance,
Call 1-800-543-6400
Please provide following information:
- Model number
- Serial number (if any)
- Part description and number as shown in parts list
Address parts correspondence to:
Attn. Customer Service
100 Production Drive
Harrison, OH 45030
6
www.chpower.com
