Chicago Electric 42417 Work Light User Manual



THANK YOU for choosing a HARBOR FREIGHT TOOLS product. For future reference, please complete the
owner’s record below:
Model__________ Serial No.___________ Purchase Date______________
SAVE THE RECEIPT, WARRANTY AND THESE INSTRUCTIONS. It is important that you read the entire
manual to become familiar with the unit BEFORE you begin assembly.
Technical Specifications
Tool Name: Spotlight, 1,000,000 Candle Power
Item Number: 42417
Housing Diameter: 6"
Battery: 12 VDC
Lens Adapter: 5"
Lens Construction: 3/16" Glass
Candle Power 1,000,000
Light Source: Quartz Halogen Bulb
Handle: 4" Pistol Grip
Trigger: Squeeze Type with Trigger Hold
Power Adapter: 120 VAC / 60 Hz<-> 12 VDC
Charger: U.L. Listed
Car Adapter: Lighter Type with 5-1/2' Cord
Tool Weight: 3 LBS.
Warning: The warnings, cautions and instructions discussed in this instruction manual cannot cover all
possible conditions and situations that may occur. It must be understood by the operator that COMMON
SENSE AND CAUTION ARE FACTORS WHICH CANNOT BE BUILT INTO THIS PRODUCT, BUT MUST BE
SUPPLIED BY THE OPERATOR.
The Operator
PLEASE REMEMBER:
Never look directly into the Spotlight.
Avoid touching the Lens as it may become hot during operation.
Do not dissassemble the Battery or remove any parts from the Battery and surrounding connections.
Do not allow the Spotlight to be exposed to fire or high heat as this may result in an explosion.
#42417 Page 2
