#42417 Page 4
Figure 1
Car Adapter (14)
Locking Trigger Hold (10)
Trigger (11)
Hanging Strap (12)
ABS Housing (1)
Lamp Lid (5)
Tripod Adapter (6)
On/Off with Locking Trigger Hold
Your Spotlight is equipped with a Trigger Hold to allow you to have the Spotlight on while leaving your hands free
for work.
Step 1) To turn on your Spotlight, press down on the Trigger (#11). Pressing down on the Trigger (#11)
will engage the Locking Trigger Hold (#10)-see Figure 1. Note: Never leave Spotlight unattended
with the Locking Trigger Hold left on.
Step 2) To release the Trigger Hold (#10), push in on the left side of the Locking Trigger Hold button
(#10) -see Figure 1.
IF THERE IS ANY QUESTION ABOUT A CONDITION BEING SAFE OR UNSAFE, DO NOT OPERATE THE TOOL.
Unpacking
UNPACK AND CHECK CONTENTS
When unpacking your Spotlight-1,000,000 Candle Power check to make sure the following parts are included. If
any parts are missing or broken, please call HARBOR FREIGHT TOOLS at 1-800-444-3353.
Parts Listing
Part # Description Quantity Part # Description Quantity
1 ABS Housing 1 8 Switch 1
2 Reflector Plastic 1 9 Battery 1
3 Bulb 1 10 Locking Trigger Hold 1
4 Glass 1 11 Trigger 1
5 Lamp Lid 1 12 Hanging Strap 1
6 Tripod Adapter 1 13 Power Adapter 1
7 Circuit Board 1 14 Car Adapter 1
Warning - Battery Disposal
The Spotlight is powered by a battery which will have a long life span. When the battery is no longer
functioning, it should be removed from the Spotlight and properly recycled. Many states require
recycling. Contact your local solid waste authority for information on recycling.
Before disposing of the battery, wrap exposed terminals with heavy tape to prevent a shorting condition,
which could cause fire and/or injury.
NEVER EXPOSE THE BATTERY TO HIGH HEAT OR FIRE; BATTERY MAY EXPLODE UNDER THESE
CONDITIONS.
REV 11/02 REV 05/05
