Page 9For technical questions, please call 1-800-444-3353.SKU 67707
Work Piece and Work Area Set Up
Designate a work area that is clean and 1.
access by children or pets to prevent
distraction and injury.
Route the power cord of the Charger 2.
along a safe route without creating a
tripping hazard or exposing the power
cord to possible damage.
Charging the Battery Pack
The Battery Pack needs to be charged
recharge the Battery after every use.
Charger
Socket
Battery
Pack
Charger Plug
Charger (506)
Figure 2
1.
surface in a room where the temperature
Allow a recently exhausted Battery Pack 2.
to cool completely before charging. Make
sure the Battery Pack is undamaged; do
not charge a cracked or leaking pack.
Insert the Charger’s plug into the 3.
Charger Socket on the Battery Pack, and
plug the Charger into a grounded, 120V
outlet. The indicator light on the Charger
will turn red showing that the battery is
charging.
When the indicator light turns green, 4.
the Battery Pack is fully charged. This
process will take approximately 90
minutes.
Unplug the Battery Pack from the 5.
Charger and the Charger from the wall
outlet.
Note: Do not use a battery pack immediately
the Charger and Battery Packs not in
use indoors, away from children.
Installing Attachments
TO PREVENT
SERIOUS INJURY
FROM ACCIDENTAL
OPERATION:
Make sure the Battery Pack is
removed from the Tool before
installing accessories, or
adjusting the tool.
To install an accessory:1.
Hold the Spindle (3) with a 13mm a.
wrench (sold separately), and unthread
the Cap Screw (1) using the Hex
Wrench (505). Remove the Cap Screw
and Retainer (2).
Cutting Blade
(502)
Four Pins on
Spindle (3)
Figure 3
b. Install the desired accessory in any one
of seven forward orientations by aligning
four of the holes in the accessory over
the four pins on the Spindle.
CAUTION: Always face the accessory away
from the handle to avoid injury.
